CNG Safety Break
SB-CNG FLVL-S
Hose Reel with manual rewind blue, TW 100, DDC-M 100 SS
Marine terminal, with grey cabinet, customised
Lube oil loading of a ship
TW 75 hose assembly, TW couplings
EN 12115 hoses: colour marking
LTW 100 hose assembly
with MC 100-51/2" Al
ERV-R 50.16 ZS 2
Red Band Rubber Expansion Joint with "ZS" limiter (tie rods with outer limitation in rubber bushings)
Type PCS 38 (Polypal Clean DN 38 mm)
AN 51/2 SS
Welding nipple 51/2" stainless steel
Adapter: MK 80-32° Ms x MK 80-32° Ms
Special type with bent levers. The lever is bent to enable lever arrest (safe position when coupled)
Vehicle refuelling with LPG (L.P. Gas, Autogas)
ZVG 2 ACME nozzle, LPG 16 hose
Offshore oilrig: TW hose assemblies, DDC Dry Disconnect Couplings
Aircraft Refuelling Skid
HD-C hose assembly, ZVA 32 nozzle, SG1Al sight glass, hose reel made by ELAFLEX Italy
oasis TH104 Tank Head Valves, CNG trailer
ERV-R 200x175.16 ZS 4
Red Band Rubber Expansion Joint, special length 175 mm, with "ZS" limiter (tie rods with outer limitation in rubber bushings)
FWS composite hoses / hose assemblies
Type FWS PP with female threaded fitting, Type FWS PTFE with stainless steel flange
Slimline dispensing hose SF (sulfur-free)
Fuel producers spend considerable effort in fulfilling the maximum allowed sulfur content. Rubber compounds of this hose type are free of sulphur – ensures that the sulphur content of the fuel is not increased, even if the medium remains for a long time within the hose
ERV Rubber Expansion Joints
Picture 1
Slimline 16 black
Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360.
CHD 32
Lilac Band chemical hose without helix, DN 32
Vehicle refuelling with LPG (L.P. Gas, Autogas)
ZVG 2 EURO (UL listed)
Slimline quality dispensing hose for the forecourt
VB 80 ADR SS / VB 100 ADR Al with pressure relief
Plug for TW female couplers
• Meets the ADR requirements
• Enhanced safety and protects the environment
• Easy, user friendly operation
Hose trolleys, HD 100 C
Type HD-C, aviation hose, Aljac bonding reel und Lanyard reel
ContiTech Production hose
vulcanisation / autoclave
Oasis Engineering Ltd, New Zealand (CNG refuelling products)
Production Picture 24
ERV VSD:
ERV with vacuum support spiral. Spiral of AISI 316 Ti, used when the vacuum resistance of the chosen ERV is not sufficient.
Elaflon PTFE 50
Universal hose with electrically conductive, seamless lining of PTFE (Polytetrafluorethylene). Suitable for all commonly used chemicals. Suitable for both suction and delivery (Type PTFE D = delivery). Working pressure up to 16 bar, burst pressure > 64 bar. Temperature range from - 30° up to + 150° Celsius (depending on medium). Steaming out for cleaning and sterilisation permissible up to 150° C, max. 30 min. Meets EN 12115. FDA und USP Class VI conform according EC regulations 1935/2004 and 10/2011.
Vehicle refuelling with LPG (L.P. Gas, Autogas)
ZVG 2 ACME nozzle
ZVG 2 K (Korea)
front view
