ZVF 50 JET overwing refuelling
with HD-C hose assembly
Oasis BV708, 1" ball valves, isolation valves, CNG spheres (tanks)
ZVA "LT" nozzles
Low Temperature type -40° C for cold regions
M 21-1" cr
Female ferrule hose coupling EN 14424, reuasable. Slimline 21 hose, red.
ZVA Slimline 2 with reduced spout and Slimline hose
here: for gasoline, use in countries without vapour recovery regulation
H2 Cover Hose 'CH-H2 38'
Nozzle Thread
TGN 2" Al (TGN 50 Al)
Tank truck flange aluminium, one end flange to DIN 28462, other end male BSP thread.
Unloading petroleum products at the service station (road tanker to UST)
LG 3" hose assembly for gravity discharge, LTW 50 hose assembly for vapour balance
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Assembling ZVA components
Maintenance at the petrol station
Section view ERV-G Rubber Expansion Joint
ELAFLEX Hamburg
Manufacturing bronze corrugated pipes
Elaflon PTFE 50 with FFX 50 SSE/SS; PCS 25 with AMKC 25 SSE/SS
Universal hoses with PFA coated fixed flange and Camlock fittings. Spannfix / Spannloc stainless steel clamps.
AMK-St 50 SS, AVK-St 50 SS
'Camlock' stainless steel female and male hose tails to EN 14420 - 7
ZVA Slimline 2 / ZVA Slimline 2 GR
Petrol station nozzles with (top) and without vapour recovery (below)
Manufacturing of turned parts
ZVA Slimline 2, guard no. 4, Sight Glass SG 1 Al, Slimline hose assembly
Accessories and spare parts: Ground cable assembly, dust cap assemblies, spouts, strainer
ER 339, ER 494, ER 495, ER 587 JET PTL, EKG 1200, GKG 19, GKG 32, GKG 38-J, ES336.1
Tank container filling coupling: MK 80-32 SS with VB 80 SS
MK 80-32° coupling with bent lever. For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Sample inspection
ELAFLEX Hamburg
Hose assemblies, marking after testing
ERV VSR:
ERV with vacuum support ring. Ring of AISI 316 Ti , used when the vacuum resistance of the chosen ERV is not sufficient.
Camlock Cam Locking hose tail AMK-St 50 Ms and male adapter AVK 50-2" Ms (brass)
Oasis 'Priority Panel' with ball valves for CNG bus refuelling
Connection road tanker to trailer: LTW hose assembly, DDC Dry Disconnect Coupling
Assembling Spannloc hose fittings
Vehicle refuelling with LPG (L.P. Gas, Autogas)
ZVG 2 EURO UL with EA 866 scuffguard, LPG 16 hose
Alternative fuels: DME Dimethyl Ester
DGC Dry Gas Coupling, EFL 16 Fluorline hose assembly
MannTek DDC-V 150 F Al, DDC-M 150-6"
