Road tanker reel with HD 50 hose assembly, ZV 500 nozzle

LPG Autogas dispenser, ZVG 2 ACME nozzle, LPG 16 dispensing hose

MK 80-90 SS; MK coupling stainless steel with bent lever 90°

TW coupling with bent lever: For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.

ERV-BR 100.16

BR Rubber Expansion Joint, special type for abrasive media such as sludges, slurries, solid / liquid mixtures and emulsions, dustlike or powdery products. Also suitable for all kinds of water (non oil containing) as well as various chemicals. Not suitable for petroleum based products. For extreme strain (e. g. sharp and rough-edged matter) we suggest the use of ERV with inner protection sleeve type SR.

Adapters / couplers for vehicles fighting dangerous goods incidents:

Adapter Sight Glass SG 2" SS/Vi with MK 50 SS/Vi and VK 50 SS/Vi

Aviation Dispenser

with VHD 100 C and HD 75 C Neon hose assemblies, SFC 100 TW and SFC 75 TW hose couplings

ZVF 50 PTL (Push-Twist-Lock), strainer inspection

SD 38 Pyropal

Steam hose with steel braids for wet saturated steam up to 18 bar (210° C) and hot water up to 120° C. For cold water up to 25 bar. Minimum burst pressure 180 bar (1 : 10 safety factor

Slimline 16 red

Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360.

Check Valve 350 bar

for Hydrogen

Overwing refuelling ZVA 25

ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany

ZVA long term testing

Polypal Clean PCS25, RMC 25

Filling of houshold cleaning bottles

DEC – Dry Evotek Couplings:

dry disconnect couplings for the chemical industry.
• Low connecting forces even against pressure
• Ergonomic handle (DN40 and bigger)
• Good transmission ratio in the cam curve
• Wide range of chemical resistance due to selection of high quality materials
• Minimized spillage during decoupling

Assembling "ZS" tie rods to ERV rubber expansion joints

UTS hose assembly, rail tanker top loading

MB 100 Al

Dust cap for VK 100, aluminium

TWD-TM coupling seal

PTFE encapsulated

Manufacturing of turned parts

AMX ammonia hose

rail tanker Loading/Unloading

ELAPHARM hose assemblies, applications

Ship bunkering with STW hose assembly and MannTek DDC Dry Disconnect Couplings

Scandinavia

Road tanker for heating oil delivery, HD hose assembly, ZH 50 nozzle, MK 80 Ms coupler with VB 80 Al dust plug

KR 50 - 21/2"

Filling of Heating Oil Tanks: New Adapter for difficult-to-reach house connectors

Fluorflex FXD universal hose assembly

extremely flexible PTFE hose with maximum bending radius

Heating oil delivery: HD reel hose, bulk nozzle

L.P. Gas rail tanker

loading and unloading with DGC Dry Gas Couplings; Use of adapters with ACME thread

GasGuard LPG nozzle GG20DN

With long connector nut to access 'hard to reach' fill points. "DN": suited for use by the general public and untrained personell (self service). Patented dual nose piece for added safety. Low lever actuation force. Gas release volume on valve closure : 1,7 cm³.

ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany

Plettenberg factory 2

ERV-G 80.TW

Yellow Band rubber expansion joint with TW flanges
