Media Library / Images

AdBlue® urea solution, road tanker:

DDC-M 50 Dry Disconnect Coupling, UTL 50 hose assembly on reel

Adapters / couplers for vehicles fighting dangerous goods incidents:

Dry Disconnect Stanag 3756 DDC- M 50 / 65 / 80 SS NOT x VK 50 SS/Vi Hose sided MK coupling can be coupled without tools

VB 80 Al

TW dust plug, aluminium

DCC Dry Cryogenic Coupling for LNG

Coupling process

Oasis NC 203 P30_P36 Nozzle Couplers

Oasis BV706, 3/4" pneumatically actuated ball valve for CNG

Tank container filling coupling: MK 80-32 SS with VB 80 SS

MK 80-32° coupling with bent lever. For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.

Unloading: MK couplers with DDC-V 80 adapter

Oasis Fill Valves at CNG service station

Oasis BV708, 1" ball valve / isolation valve, CNG fill post for trailer loading with HC200 Quick Coupler

Hose assemblies for LPG

DN 25, DN 32, DN 50 / with flange connection, ACME connection, NPT thread

Hose Reel with hydraulic rewind system blue, TW 100, DDC-M 100

Urea solution filling for light vehicles – parallel to Diesel refuelling

ZVA LV for AdBlue^® / ZVA Slimline 2

Type PCS, Polypal Clean

PCS 25, PCS 63, PCS 100

Road tanker with open hose reel, HD hose assembly, ZV 500 nozzle

Hose with SC 50 SS Spannloc stainless steel clamps - corrosion protection against road salt

Filling plant for special gasoline types

ZVA 25 solvent type with special seals, Slimline hose assemblies

ZVF 50 UL91 overwing refuelling

UL 91: new unleaded aviation fuel - identification colour green

IBC Hose Coupling MC 38-S 60 SS, MX 38-S 60 SS

direct connection to the standard outlet S 60 of IBC

DEC – Dry Evotek Couplings:

dry disconnect couplings for the chemical industry.
• Low connecting forces even against pressure
• Ergonomic handle (DN40 and bigger)
• Good transmission ratio in the cam curve
• Wide range of chemical resistance due to selection of high quality materials
• Minimized spillage during decoupling

ERV-W 80.16

WHITE BAND Rubber Expansion Joint for foodstuffs, also containing oil and fat. Liner corresponds to Recommendation XXI of BfR and FDA-21CFR 177.2600. Not approved for drinking water. Temperature range (depending on medium) - 20° C up to + 90° C, temporarily up to 100° C. Electrically non-conductive.

ZVA 25 for AVGAS

red scuffguard, AVGAS sticker; Slimline hose assembly

Production MannTek, Sweden

Rubber Expansion Joint ERP 80.16

RED SPOT expansion joints for sanitary installations, highly flexible, for cold and warm water, pool water, sea water, drinking water. Temperature range (depending on medium) - 40° C up to + 90° C, temporarily up to + 120° C. Electrically dissipative.

ZVF 50 JET overwing refuelling

with HD-C hose assembly

KWZ x MK 80-32°

Rail car adapter with TW coupler, bent lever

MannTek DGC DryGasCouplings for L.P. Gas

DGC-M 50-2" with DDC-S dust plug

LPG Autogas dispenser, ZVG 2 ACME nozzle, LPG 16 dispensing hose

LPG 200 / LPG 100

Bunkering hoses for L.P. Gas with SFC flanged hose couplings

Rail tanker unloading of petroleum based products

LTW hose assemblies; Poland

Terminal / gantry: 'Polypal Oil' hose assemblies for bottom loading of road tankers

Lining UPE - resistant to all petrochemical media, also with high content of aromatics or other aggressive additives; cover CR - oil resistant
