ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany

Sand casting ZVA

Dantec Production hose

Composite hoses: hose marking on ferrule

ELAFLEX Hamburg

ERV marking after test

Safety Swivel Break

SSB 25

Construction site / on site refuelling:

ZVA 500 manual bulk nozzle

Rail tanker unloading of petroleum based products

LTW 75 (hose), MKX 75 ('TW' female coupler with Spannfix clamps), Adapter KWZ x VK 80 (51/2" x 'TW'-male coupler)

Lube Flow Modul for IBC loading/unloading

FWS 50 PP, DDC-M 50, HD 50, ZV 400, ERV-G 50 Special Type

Marking of High Temperature Types ZVA Slimline 2 / ZVA Slimline 2 GR

For regions with exceptionally hot summer conditions which may lead to particularly high fuel temperatures we offer High Temperature (HT) nozzle types, available for ZVA Slimline 2 and ZVA Slimline 2 GR.

ZVA Slimline 2 GR - spout with vapour suction inlet

HD 38 C NEON, Aljac bonding reel

Airfield refueller (e-refuelling technology)

H2 Cover Hose 'CH-H2 38'

Safety Break Thread

SSB 25 Safety Break: Abriss

BD 63, Hose Beads at airport depot

Hot stamping process, TW coupling part

Stainless steel couplings with PFA coating, type "...SSE"

Surface in contact with the medium additionally coated with Teflon® PFA. This type is used if stainless steel does not have a sufficient chemical resistance (i.e. for hydrochloric acid and iron-III-chloride) and polypropylene is not possible because of insufficient stability. Available in all standard sizes.

Ship bunkering

Taking probes; VK coupling

ZVA LV for AdBlue® with SSB 16 LV SL 16 for AdBlue® hose assembly (blue)

Refuelling with ZVA Slimline 2 nozzle

Scuffguard, Product Sleeve and Colour Sleeve in grey special colour

V 16-3/4"

Male ferrule hose coupling EN 14424, reusable. Slimline 16 hose, red.

Camlock couplings:

stainless steel female and male couplings to EN 14420 - 7

Hose Trolley HTR-T

for terminal operations

AN 51/2 SS

Welding nipple 51/2" stainless steel

Equipment truck for dangerous goods accidents

suitable hose assemblies and adapters from Elaflex, ELAFLEX_Information_2.17E.pdf

Tank container filling coupling: MK 80-32 SS with VB 80 SS

MK 80-32° coupling with bent lever. For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.

VB 50 SS

TW dust plug, stainless steel

Rubber Expansion Joint ERV-G 80.16

YELLOW BAND expansion joints suitable for petroleum based products with aromatic content up to 50%, fuels (ethanol content up to 85 %), aviation fuels, town gas and natural gas except liquefied petroleum gas. Temperature range (depending on medium) - 20° C up to + 90° C, temporarily up to + 100° C. Electrically dissipative.

ZVF 50 AVGAS overwing refuelling

with HD-C hose assembly

Elaflon PTFE

Universal hose with electrically conductive, seamless lining of PTFE (Polytetrafluorethylene). Suitable for all commonly used chemicals. Suitable for both suction and delivery (Type PTFE D = delivery). Working pressure up to 16 bar, burst pressure > 64 bar. Temperature range from - 30° up to + 150° Celsius (depending on medium). Steaming out for cleaning and sterilisation permissible up to 150° C, max. 30 min. Meets EN 12115. FDA und USP Class VI conform according EC regulations 1935/2004 and 10/2011.

ELAFLEX quality: section view of a ERV bellows

Hot stamping process, production TW coupling parts
