LPG terminal: loading with DGC Dry Gas Couplings
Nozzles and hose assemblies for L.P. Gas (LPG, Autogas)
Aircraft refuelling Hose Reel
rewind
ELAFLEX Hamburg
Hose stock
Ship loading various media - STW 150 and UTS 150 hose assemblies
Camlock cam locking couplings:
Attachment AMB dust cap with chain to Spannfix clamps (service free of charge)
Camlock cam locking couplings:
Attachment AVB dust plug with chain to Spannloc clamps (service free of charge)
RMX 32 SS / SS
Spannloc threaded hose coupling with foodstuff thread / Spannloc of stainless steel
90° Bend Al
90° bend of aluminium with pipe thread (EN ISO 228 with flat sealing surface). Available in sizes G 2" and 3". On request with TW couplings.
Fuel delivery at the petrol station
LTW 75 fuel delivery hose, MKX 80 female TW coupler
GasGuard LPG nozzle GG30
4-slot design to facilitate connection of the nozzle to the vehicle fill point. New nose piece design to reduce the released gas upon valve closure, incorporating improved gas release method to minimise the risk of splash back.
ZVA 25 with Z-Swivel
Boat Refuelling
Elaflon PTFE 38, AMKC 38
Universal hose, Elaflex Camlock quality coupling
Composite hose Danoil 7GG, DDC-M Dry Disconnect Coupling, airport depot
Ship bunkering with LNG
DCC Dry Cryogenic Coupling with cap; CBC Cryogenic Breakaway Coupling
ELAFLEX Hamburg
Hose assemblies, endoscope inspection hose
Underwing refuelling, HD-C hose assembly
Hydrant dispenser
ELAFLEX Hamburg
ERV pressure testing
GasGuard LPG nozzle GG1DN
suited for use by the general public and untrained personell (self service). Patented dual nose piece for added safety. Low lever actuation force. Gas release volume on valve closure: 1.7 cm³.
DN 1" Ms
Double nipple brass
Elaflex hose assemblies and Rubber Expansion Joints
Example of a marking of test data (hydrostatic test) of a hose assembly
Rail tanker unloading of petroleum based products
Plant side: FWS PP St/St composite hoses, SG 3" Sight Glasses
ELAFLEX refuelling equipment:
Quality is in the detail.
ZVA Slimline 2 GR with Sight Glass SG-COAX
ZVA Slimline 2 GRVP - spout with vapour suction inlet
Filling plant for special gasoline types
ZVA 25 solvent type with special seals, Slimline hose assemblies
Elaflon PTFE 50
Universal hose with electrically conductive, seamless lining of PTFE (Polytetrafluorethylene). Suitable for all commonly used chemicals. Suitable for both suction and delivery (Type PTFE D = delivery). Working pressure up to 16 bar, burst pressure > 64 bar. Temperature range from - 30° up to + 150° Celsius (depending on medium). Steaming out for cleaning and sterilisation permissible up to 150° C, max. 30 min. Meets EN 12115. FDA und USP Class VI conform according EC regulations 1935/2004 and 10/2011.
Hose assemblies for petroleum based procucts
LTW 75, VX 80-3, MannTek DDC-M80-3Ms & TW 63, SFX 63 TW
ELAFLEX Hamburg
Certificate pressure test
