FFBV 80, DAC-V 65, DAC-K 2 1/2" Al

MannTek Full Flow Ballvalves (FFBV), one way

ZVF 50 UL 91 / green

Manual aviation fuelling nozzle for overwing service. Flowrate up to 400 ltr. / min. (85 IGM – higher flowrates are possible). Size DN 50. Working pressure PN 10 (140 psi). Temperature range - 40° C up to + 55° C.

Urea solution filling of a car:

ZVA LV for AdBlue^®, Slimline 16 for AdBlue^® (blue cover)

VB 80 ADR SS with pressure relief

Plug for MK 80
• Meets the ADR requirements
• Enhanced safety and protects the environment
• Easy, user friendly operation

LPG Autogas dispenser

ZVG 2 ACME + ZVG 2 DISH nozzle, LPG 16 hose, ARK 19 Safety Break

Oasis TH Tank Head Valve, for CNG

Camlock hose couplings: system comparison

right hand side - industry standard, with cable tighteners to fix levers. Left hand side: Easyloc from Elaflex with automatically secured levers.

ELAFLEX Hamburg

ELAFLEX stock hoses

LPG ship-to-ship cargo transfer

Danchem PASS composite hose

Elaflon Plus FEP 75, MK-A 80 SS

Loading and unloading of chemicals. TW coupling with active safeguard lever

DDC-V Dry Disconnect Couplings for various media

tank storage; TW hose assembly

ElaSil® Silicone hose assemblies DN 13-102

For for high media purity requirements, easy to clean. Suitable for Pharma, foodstuff and cosmetics industry. Homogeneous hose construction of platinum cured, translucent and phtalate free Silicone (FDA / USP), resistant to kinking and highly flexible. Large temperature range -60° C to +200° C. Available as complete hose assembly with crimped fittings, DN 13 to 102. Here: DN 25 with Camlock Cam Locking Coupling and Triclamp connection

ZVA HV for AdBlue®, SSB 16 SS, SL 16 for AdBlue®, Elafix 40

Urea solution (DEF, ARLA 32) for trucks: nozzle, Safety Break, hose assembly and adapter for the vehicle AdBlue^® filler inlet to avoid misfuellings.

Underwing refuelling, HD-C hose assembly

Hydrant dispenser

TW hose for fire fighting vehicle with extremely long telescopic crane

Slimline hose assembly, section view

Slimline SF 19 black

Quality petrol pump hose for gasoline and diesel fuels. Special type 'sulphur-free'. Sulphur content of fuel does not increase, even if medium remains with the hose for a longer time, see Information 12. 15 and catalogue page 111c.

ZVA Slimline 2 GR, special type with bellows, black, guard 3 - side view

Rail tanker discharge coupling KWK, with elbow DN 80

for damaged / dirty rail tanker or other threaded hose connections. Used e.g. for environmental protection trucks

SPANNLOC bolted Sicherheits Klemmbacken aus aluminium

SC 75 Al

ELAFLEX Hamburg

Assembling bunker hose

VK 50 SSE

TW male adapter. Material: stainless steel with universally resistant PFA coating (red)

Spannloc hose clamps of stainless steel for chemical hoses

Adapters / couplers for vehicles fighting dangerous goods incidents:

Adapter Rail Tanker Dischharge Coupling KWK SS/Vi x VK 50 SS/Vi

Vehicle refuelling with LPG (L.P. Gas, Autogas)

ZVG 2 EURO

ELAPHARM Type EPH 25

electrically isolating 'I', with blue cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, white PTFE liner. Clamp fittings, lining flared (free of dead spaces).

Camlock Cam Locking hose tail AMK-St 50 Ms and male adapter AVK 50-2" Ms (brass)

DEC – Dry Evotek Coupling

Dry disconnect coupling for the chemical industry

L.P. Gas rail tanker

loading and unloading with DGC Dry Gas Couplings, LPG hose assemblies. Vehicle side: DGC-V male couplings with flange

Requirements to a Hose

(German)
