ELAFLEX Hamburg
Assembling COAX hose SL 21, with inner vapour hose, for vapour recovery Stage II
Oasis Engineering Ltd, New Zealand (CNG refuelling products)
Production Picture 3
Cargo loading of a tanker with petroleum based products; FHD hose assembly
Picture courtesy of Macoil International, Gibraltar
PAL hoses for the chemical industry
VB 80 SSE
TW dust plug of stainless steel, surface in contact with the medium additionally coated with Teflon® PFA. This type is used if stainless steel does not have a sufficient chemical resistance (i.e. for hydrochloric acid and iron-III-chloride) and polypropylene is not possible because of insufficient stability. Available in all standard sizes.
Rail tanker unloading of petroleum based products
LTW hose assemblies, TW couplings
ZVF 25 for aircraft refuelling
dust cap and ground cable assembly
Road tanker connection hose to trailer with bend KR 50, HD 50 hose assembly MX 50-2" Ms
LPG road tanker loading with MannTek DGC Dry Gas Couplings
ZVA Slimline 2 GR nozzle
with Coax hose assembly (one side open end, inner vapour hose visible)
Colour production: manifold
UTS and FWS hose assemblies
M 21-1" cr
Female ferrule hose coupling EN 14424, reuasable. Slimline 21 hose, yellow.
Example of a marking of test data (hydrostatic test) of a hose assembly
KSS-SD of stainless steel
for saturated steam hoses. These hose assemblies are subject to high wear. The main stress area for hose assemblies is also at the joint end is protected.
ERV-GS
"Yellow Steel" Rubber Expansion Joints / ship engine room
KR 50 - 21/2"
Filling of Heating Oil Tanks: New Adapter for difficult-to-reach house connectors
ELAPHARM Type EPH
electrically isolating 'I', with blue cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, white PTFE liner. Clamp fittings, lining flared (free of dead spaces).
LNG Refuelling
N-LNG Nozzle, push handles to couple
ERV-GR 80.16 ZS 2
GREEN BAND Rubber Expansion Joint with "ZS" limiter (tie rods with outer limitation in rubber bushings)
LeverAssist hold-open aid for ZVA Slimline 2 nozzles
Detail
Petrol station in Mexico
ZVA Slimline 2 nozzle, SSB 16 Safety Break, Slimline hose assembly
Forklift refuelling with LPG (L.P. Gas, Autogas)
GasGuard nozzle, LPG 16 hose
UTS 200 hose assembly in chemical plant
Italy
EASYLOC Cam Locking Coupling
easy deactivation of lever arrest
HD-C NEON hose with new, REFLECTING marking
Hosebun® hose saddle 'HSB'
provides for a professional and material-protecting suspension of hose assemblies
ELAPHARM and SD Pyropal steam hose
Pharmaceutical production
ERV-G Yellow Band rubber expansion joints, pumping system for oil emulsion
Oasis FV103 45° Fill Valve with NC 203 P30 Nozzle, for CNG
ELAFLEX Hamburg
Assembling dispensing hose
