MannTek SBC Safety Breakaway Coupling with breaking pins: Detail breaking pins
ELAFLEX Hamburg
Assembling ERV large DN
Tank container filling coupling: MK 80-32 SS with VB 80 SS
MK 80-32° coupling with bent lever. For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.
Universal hose UTS 50
Camlock Cam Locking male adapter AVK 50-2" Ms (brass)
ERV-R 80.16 SS TA
Red Band Rubber Expansion Joint with "TA" PTFE lining
TW coupler MK 80 SS-90° (bent lever) and dust plug VB 80 ADR SS with pressure relief
NB-ZVF 50 SR, ER 583 PTL
Nozzle boot f. ZVF 50 with additional spout retainer
MannTek DDC-V & DDC-M Dry Disconnect Couplings
Refuelling with ZVA Slimline 2 nozzle
Scuffguard, Product Sleeve and Colour Sleeve in grey special colour
Oasis FV103 Fill Valve, NC 104 Nozzle Coupler, CNG bus refuelling of small truck
AN 2 Al
Welding nipple aluminium
Flexible bronze pipe connectors
Installed in suction pipe between dispenser and underground storage tank
MannTek Dry Disconnect Couplings:
DDC-V 50-2", DDC-V 50 F, DDC-M 50-2", DDC-M 80-3"
Chemical manifold
FEP 5O, MannTek DDC-M 5O SS
Polypal Oil 75
Universal chemical hose special type with petroleum resistant cover of Chloroprene (CR). Suitable e.g. as gantry hose (road tanker loading).
ELAFLEX refuelling equipment:
Quality is in the detail.
ERV-OR 65.25
ORANGE BAND Rubber Expansion Joint for Liquid Petroleum Gas (LPG) acc. to EN 589. For tank trucks and refuelling stations. Temperature range (depending on medium) - 20° C up to + 90° C, temporarily up to 100° C. Electrically dissipative.
Hose Beads
BD 50, BD 63
ELAPHARM Type EPH-OHM G
electrically conductive 'OHM/T', with light grey cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, black PTFE liner.
Cargo loading of a tanker with petroleum based products; FHD hose assembly with new longitudinal stripe to avoid torsion
Picture courtesy of Macoil International, Gibraltar
Double Closing Safety Swivel Break
SSB 16 DC
Double Closing COAX Safety Break
CSB 21 DC
L.P. Gas rail tanker
loading and unloading with DGC Dry Gas Couplings; Use of adapters with ACME thread
ELAFLEX refuelling equipment for LPG (Autogas, L.P.Gas)
MB 80 SSE
TW dust cap of stainless steel, surface in contact with the medium additionally coated with Teflon® PFA. This type is used if stainless steel does not have a sufficient chemical resistance (i.e. for hydrochloric acid and iron-III-chloride) and polypropylene is not possible because of insufficient stability. Available in all standard sizes.
Bunker boat: TW hose assemblies, TW couplings
Hose Trolley HTR-T
for terminal operations
ERV-G Yellow Band rubber expansion joints, pumping system for oil emulsion
