Elaflon Plus FEP hose assembly, crimped foodstuff fitting

Elaflon Plus FEP hose assembly, crimped foodstuff fitting

ERV TA:

ERV TA:

ERV with white PTFE lining. Used when the chemical resistance of the chosen ERV type is insufficient. Resistant to all commonly used liquids. Electrically isolating, therefore not suitable for flammable liquids in Ex-Zones. Admissible working temperature of expansion joint has to be observed. For maximum pressure of 6 bar – not suitable for vacuum.

Rubber Expansion Joint ERV-G LT 80.16

Rubber Expansion Joint ERV-G LT 80.16

YELLOW BAND LT expansion joints designed for low temperature applications for standard-conform petroleum based products, e.g. diesel, heating oil up to + 90° C, aviation fuels, petroleum up to + 60° C and gasoline up to + 40° C. Temperature (depending on medium) range - 40° C up to + 90° C, temporarily up to + 100° C. Electrically dissipative.

Elapharm clamp fittings

Elapharm clamp fittings

Elaflon Plus FEP hose assemblies:

Elaflon Plus FEP hose assemblies:

Bulk filling of powders

Rail tanker unloading of petroleum based products

Rail tanker unloading of petroleum based products

LTW hose assemblies; Poland

MC 75-3" SS

MC 75-3" SS

Female hose coupling for hoses, stainless steel, with Spannloc clamps

Helicopter refuelling winter / Canada

Helicopter refuelling winter / Canada

ZVF 50, HD 50 C NEON

ZVA-RG

ZVA-RG

Automatic nozzle ZVA DN 19, of red bronze (gunmetal), for solvents and corrosive media. Flowrate up to 60 l / min.

Scuffguard for ZVG 2 nozzles: type EA 866

Scuffguard for ZVG 2 nozzles: type EA 866

with integrated fuel grade identification to European rules and large advertising/printing surface. Available in orange and black

Vehicle refuelling with LPG (L.P. Gas, Autogas)

Vehicle refuelling with LPG (L.P. Gas, Autogas)

GasGuard GG20 ACME nozzle

ZVF 50 UL91 overwing refuelling

ZVF 50 UL91 overwing refuelling

UL 91: new unleaded aviation fuel - identification colour green

Fuel Grade Identification to EN 16942 for ZVA Nozzles

Fuel Grade Identification to EN 16942 for ZVA Nozzles

Type EK FGI

Rubber Expansion Joint ROTEX 80.16

Rubber Expansion Joint ROTEX 80.16

ROTEX expansion joints suitable for permanent use with hot heating water, cooling water and hot air. Approved according to DIN up to 100° C by 10 bar and up to 110° C by 6 bar. Temperature range (depending on medium) - 40° C up to + 130° C, temporarily up to + 150° C. Electrically dissipative.

Lube oil filling, ZV 19 manual nozzle

Lube oil filling, ZV 19 manual nozzle

Construction of ELAFLEX composite hoses type FWS

Construction of ELAFLEX composite hoses type FWS

Sectioned view of a composite hose, denomination of the components (English)

ZVA 32 for aircraft refuelling

ZVA 32 for aircraft refuelling

black plastic cover (scuffguard), Sight Glass, dust cap and ground cable assembly

ZVG 2 K (Korea)

ZVG 2 K (Korea)

suitable for passenger and heavy duty vehicle refuelling in markets utilising the 'J15' fill point receptacle.

LPG road tanker loading with MannTek SBC Safety Breakaway Couplings

LPG road tanker loading with MannTek SBC Safety Breakaway Couplings

NB-ZVF 50

NB-ZVF 50

Noozle Boots for ZVF 50 Overwing Nozzles

V 19-3/4" NPT

V 19-3/4" NPT

Male ferrule hose coupling EN 14424 stainless steel, reusable. Slimline 19 SF (sulphur free) hose, black.

MannTek FFVB Ball Valve at tanker

MannTek FFVB Ball Valve at tanker

ELAPHARM Type EPH 25

ELAPHARM Type EPH 25

electrically isolating 'I', with blue cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, white PTFE liner. Clamp fittings, lining flared (free of dead spaces).

ZVA Slimline 2

ZVA Slimline 2

with Sight Glass

ELAFLEX quality: section view of a ERV bellows

ELAFLEX quality: section view of a ERV bellows

ELAPHARM Type EPH-OHM G

ELAPHARM Type EPH-OHM G

electrically conductive 'OHM/T', with light grey cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, black PTFE liner.

FWS 50 PTFE

FWS 50 PTFE

Composite hose with PTFE lining

Cargo loading of a tanker with petroleum based products; FHD hose assembly

Cargo loading of a tanker with petroleum based products; FHD hose assembly

Picture courtesy of Macoil International, Gibraltar

Elaflex Pacific (Australia)

Elaflex Pacific (Australia)

ZVA Slimline 2, ZVA Slimline 2 GR, ZVA 25

ZVA Slimline 2, ZVA Slimline 2 GR, ZVA 25

Petrol station Portugal
