Cargo loading of a tanker with petroleum based products; FHD hose assembly with new longitudinal stripe to avoid torsion
Picture courtesy of Macoil International, Gibraltar
Storz coupling on road tanker
Hose assembly with Spannfix clamp and stainless steel threaded connection
Hose assemblies
Universal hose UTS 50 with DDC-M 50-2"; Tanker hose for petroleum based products LTW 75 with DDC-M 80-3"
L.P. Gas road tanker: long hose reel, LPG 32 and LPG 25 hose assemblies
ZVA Slimline 2 LT & ZVA Slimline 2 GR LT nozzles
Use of special seals for cold regions
ELAFLEX Hamburg
New narrow aisle stock (2018)
Fuel delivery at the petrol station
LTW 75 fuel delivery hose, GPS 50 vapour balance hose
ROTEX 200.10 SS TAS
Rubber Expansion Joint with PTFE lining and PTFE vakuum support ring
Helicopter refuelling winter / Canada
ZVF 50, HD 50 C NEON
Double Closing Safety Swivel Break
SSB 16 DC
ELAFLEX Tanktechnik, Production Plettenberg / Germany
Manufacturing of turned parts
Aljac bonding reel
Airfield refueller
Production MannTek, Sweden
ERV with FSH:
Flame protection cover (open)
ZVA Slimline 2 GR, black, guard 3 - side view B
Swivel EA 075 A f. ZVA HV for AdBlue®
new design
KWZ x MK 80-32°
Rail car adapter with TW coupler, bent lever
Production MannTek, Sweden
ERV RG:
Angular limiter
ERV-G 150 TW, ERV-G 100 TW, ERV-G 80 TW
Elaflon PTFE hose asemblies
M 21-1" cr
Female ferrule hose coupling EN 14424, reuasable. Slimline 21 hose, black.
SMX 50-2"
Female hose coupling of steel with Spannfix clamps
ELAPAC FD flat sealing material
2 or 3 mm thickness, available as coil, standard size seal or in custom shape. An elastic flange seal for tank truck and tank plant construction etc., where rough sealing surfaces require a high adaptability, where flange seals should still have good flexibility to avoid pipe fractures or simple sealing materials because little or no force can be used to tighten the joint.
KSS-SD of stainless steel
for saturated steam hoses. These hose assemblies are subject to high wear. The main stress area for hose assemblies is also at the joint end is protected.
Road tanker Sweden
large reel with HD hose assembly, DDC-V (Dry Disconnect Coupling, tank unit) and DDC-K (caps)
Oil supply system
ZV 25 manual nozzles, hose assemblies
Hot stamping process, production TW coupling parts
Oasis Engineering Ltd, New Zealand (CNG refuelling products)
Production Picture 24
SG-COAX_Al
Sight Glass, to EN 13617-1, for ZVA Slimline 2 GR with vapour recovery. Installation between petrol station nozzle and hose assembly, or mounting on the dispenser. For the visual control of bubble-free dispensing and fuel colour (e. g. for premium fuels). Suitable for all standardised fuels.
