Lightweight Gravity Discharge Road Tanker Hose LG 3"

with VX 75-3" Al LG

ElaSil® Silicone hose assemblies DN 13-102

For for high media purity requirements, easy to clean. Suitable for Pharma, foodstuff and cosmetics industry. Homogeneous hose construction of platinum cured, translucent and phtalate free Silicone (FDA / USP), resistant to kinking and highly flexible. Large temperature range -60° C to +200° C. Available as complete hose assembly with crimped fittings, DN 13 to 102. Here: DN 25 with Camlock Cam Locking Coupling and Triclamp connection

Product Badges EK 145 with design to customer specification

https://elaflex.de/en/apps-services/badgecreator

https://elaflex.de/en/apps-services/badgeselector

Terminal loadingarm

'SBC-C'

TW coupler MK 80 SS-90° (bent lever) and dust plug VB 80 ADR SS with pressure relief

VX 38-11/2" SS

Spannfix male hose coupling, stainless steel

Production MannTek, Sweden

Aircraft refuelling: MannTek sampling unit in hydrant system

H2 Hydrogen

ERV-H2+ DN 80

PHD 63

Aircraft refuelling hose special type with non metallic plastic helix and thick wall for enhanced lateral stability. Burst pressure > 80 bar

ZVA Slimline 2 GR

blue scuffguard, blue produc sleeve, guard no. 4

Movable Storage Hose Reel with manual rewind system white, HD 38, ZV 400

customised

L.P. Gas rail tanker

loading and unloading with DGC Dry Gas Couplings, LPG hose assemblies. Vehicle side: DGC-V male couplings with flange

ZVA_AdBlue_LV_2-Stufen-Anschlag_Step1

Use - 1/2

VHD Neon aircraft refuelling hoses

Aircraft dispenser

ZVA Slimline 2 GR, black, guard 3 - side view

Stainless steel couplings with PFA coating, type "...SSE"

Surface in contact with the medium additionally coated with Teflon® PFA. This type is used if stainless steel does not have a sufficient chemical resistance (i.e. for hydrochloric acid and iron-III-chloride) and polypropylene is not possible because of insufficient stability. Available in all standard sizes.

Rubber Expansion Joint ERV-G LT 80.16

YELLOW BAND LT expansion joints designed for low temperature applications for standard-conform petroleum based products, e.g. diesel, heating oil up to + 90° C, aviation fuels, petroleum up to + 60° C and gasoline up to + 40° C. Temperature (depending on medium) range - 40° C up to + 90° C, temporarily up to + 100° C. Electrically dissipative.

ELAPHARM Type EPH

electrically isolating 'I', with blue cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, white PTFE liner. Clamp fittings, lining flared (free of dead spaces).

ELAFLEX Hamburg

Assembling Spannloc hose clamps

CHD 32

Lilac Band chemical hose without helix, DN 32

LMD 32 Blue Band solvent hose

without helix

ContiTech Production ERV

Calender - preparation of rubber batch

Tecnopal 38

Chemical hose to EN 12115 for alkalis, acids, solutions, alcohols, polar solvents, acetates, aldehydes, esters, ketones, hot water, hot air (not oily).

Hose assembly for petrol stations

Standard hose SL 16

ZVG 2 K (Korea)

suitable for passenger and heavy duty vehicle refuelling in markets utilising the 'J15' fill point receptacle.

Oasis BV 708 1" Ball Valve for CNG

ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany

Assembling ZVA components

Rubber Expansion Joint ERV-W 80.16

WHITE BAND expansion joints for foodstuffs, also containing oil and fat. Liner corresponds to Recommendation XXI of BfR and FDA-21CFR 177.2600. Not approved for drinking water. Temperature range (depending on medium) - 20° C up to + 90° C, temporarily up to 100° C. Electrically non-conductive.

ZVA Slimline 2 GR, Bügel 1, Product Sleeve blue, Coax hose assembly with Colour Sleeve blue
