Urea solution filling of a car:
ZVA LV for AdBlue®, Slimline 16 for AdBlue® (blue cover)
ERV-G 50x160
Fuel mixer / blender
DCC Dry Cryogenic Coupling for LNG
Coupling process
Check Valve 350 bar
for Hydrogen
Ship loading various media - STW 150 and UTS 150 hose assemblies
Double Closing Safety Swivel Break
SSB 16 DC
GSD 50 PU
Coupling seal for TW couplings, polyurethane
DAC-V 65, DAC-M 65
Aircraft refueller , Dry Aircraft Coupling to ISO 45 for bottom loading - with and without sight glass
SG1" 1x0 Al, EA075.1, EA375.0AF, DG 50.1 Al, DG 50.2 Al
Elaflon Plus FEP 25
ELAFLEX Hamburg
Aerial view over the ELAFLEX premises
VX 38-11/2" SS
Spannfix male hose coupling, stainless steel
DN 1" Ms
Double nipple brass
Cabinet of road tanker:
hose tubes, MK 100, MK 80, hose assemblies
Road tanker Sweden
large reel with HD hose assembly, DDC-V (Dry Disconnect Coupling, tank unit) and DDC-K (caps)
Anti-Kinking Spiral 'KSS'
The main bending stress area for hose assemblies is directly behind the coupling. To reinforce this area we developed the new Anti-Kinking Spiral 'KSS': suitable for all ELAFLEX hoses, recommended for dynamically strong stressed universal hoses with thermoplastic linings
CNG Safety Break with Extention 'EL' (Extended Length) SB-CNG FLVL-EL-J
SB-CNG FLVL-EL-J
SG 1" 1x0 Al
Sight Glass, to EN 13617-1, DN 25, for installation between petrol station nozzle and hose assembly, or mounting on the dispenser. For the visual control of bubble-free dispensing and fuel colour (e. g. for premium fuels). Suitable for all standardised gasoline and diesel fuels according EN 589 + EN 590, including ethanol or biodiesel content, also Avgas and Jet-A1.
Oasis DMI Dispenser Manifold for CNG
Mobile tank for solvents
hose assembly UTS 50 with MKX 50 SS and VB 50 SS
GasGuard LPG / Autogas refuelling equipment
Nozzles, nozzle boot for dispenser installation, LPG 16 hose assemblies, Safety Break ARK 19
ZVF 50 JET
Manual aviation fuelling nozzle for overwing service. Flowrate up to 400 ltr. / min. (85 IGM – higher flowrates are possible). Size DN 50. Working pressure 10 bar (140 psi). Temperature range -40° C up to +55° C
L.P. Gas rail tanker
loading and unloading with DGC Dry Gas Couplings, LPG hose assemblies. Vehicle side: DGC-V male couplings with flange
ELAFLEX refuelling equipment:
Quality is in the detail.
Rail tanker unloading of petroleum based products
FWS PP St/St composite hose, MannTek Dry Disconnect Coupling, KWZ adapter
Aircraft refuelling Hose Reel
rewind
DDC-K 3" Al ADR with pressure relief
Cap for DDC-V 80
• Meets the ADR requirements
• Enhanced safety and protects the environment
• Easy, user friendly operation
Colour production: manifold
UTS and FWS hose assemblies
Elaflex hoses
HD, TW, LPG, FXD, SL, FEP, CHS, LMS, UTS, PTFE, PCS
Dantec Production hose
Composite hoses: hose marking on ferrule
