Vehicle refuelling Korea with LPG (L.P. Gas, Autogas, Propane)
ZVG 2 K nozzle, LPG 16 hose assembly
ZV 500 for chemials
Bulk filling of Methylene Chloride
Terminal / gantry: 'Polypal Oil' hose assemblies for bottom loading of road tankers
Lining UPE - resistant to all petrochemical media, also with high content of aromatics or other aggressive additives; cover CR - oil resistant
ZVG 2 K (Korea)
with EA 866 scuffguard / nozzle talker
Oasis FV103 45° Fill Valve with NC 104 Nozzle, for CNG
ELAFLEX Hamburg
ELAFLEX stock hoses
ELAFLEX Hamburg
Delivery trucks, loading ramps
ELAPHARM Type EPH-OHM G
electrically conductive 'OHM/T', with light grey cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, black PTFE liner. Clamp fittings, lining flared (free of dead spaces).
ERV-R ... ZS
"Red Band" Rubber Expansion Joints with limiters
Connection aircraft refueller to flanged hose assembly
ERV-G 100 TW, HD 100 C, TW-flange
ZVA 25
HIFLO-Automatic nozzle DN 25 (1"), flowrate up to 140 litres/min.
H2 Cover Hose 'CH-H2 38'
Safety Break Thread
Elapharm EPH 25 with EN 1092-1flange fitting, free of dead spaces
Connection road tanker to trailer: LTW hose assembly, DDC Dry Disconnect Coupling
Refuelling with ZVA Slimline 2 nozzle
Scuffguard, Product Sleeve and Colour Sleeve in grey special colour
Petrol station in Mexico
ZVA Slimline 2 nozzle, SSB 16 Safety Break, Slimline hose assembly
Hose Reels electrical rewind system yellow
for water
L.P.Gas petrolstation, GG20, Slimline, ZVG 2 EURO UL
ELAFLEX Hamburg
Assembling ERV large DN
MK 80-3" AG Ms
TW coupler of brass, to EN 144260-6. Special type with 3" male BSP connection
ZVA Slimline 2 DSA, Prepay Dispenser
DSA: Pressure Controlled Safety Shut-Off
Manufacturing of turned parts
Butapal LPG 10
L.P.Gas hose DN 10
Elaflon Plus FEP 25
Universal hose ELAFLON PLUS FEP with seamless FEP lining, resistant to all commonly used chemicals, see resistance chart. Suitable for both suction and delivery (Type FEP D = delivery only). W.P. up to 16 bar, burst pressure > 64 bar. Temperature range from - 30° C up to + 100° C, briefly up to 130° C. Steaming out for cleaning and sterilisation permissible up to 150° C, max. 30 min (open system). Meets EN 12115.
90° Bend Al
90° bend of aluminium with pipe thread (EN ISO 228 with flat sealing surface). Available in sizes G 2" and 3". On request with TW couplings.
DDC-M 100, TW hose assembly
Rail tanker bottom loading with Dry Disconnect Coupling
Fuel Grade Identification to EN 16942 for ZVA Nozzles
Type EK FGI - attach with Product Badge EK 145
ZVA Slimline 2
with Sight Glass
SD Pyropal hose assemblies for saturated steam in the chemical industry
MS 19-3/4" hose fittings for saturated steam
Rail tanker unloading of petroleum based products
LTW hose assemblies, TW couplings
