Fuel Grade Identification to EN 16942 standard, direct print on product badges for ZVA Nozzles
Picture 2
Elaflex hose assemblies
Hose fittings: threaded, flanged, quick couplings, Dry Disconnect Couplings
ZVA 25 spout with stainless steel tip
ELAFLEX Hamburg
Manufacturing bronze corrugated pipes
HB 50 ST tar spraying hose
Pressure hose for road construction machines, especially for hot bitumen and heavy heating oil. Temperature range: - 25° C up to + 220° C. Meets EN 13482, Type 2 SB/B (DN 19 and DN 32 analogue).
Equipment truck for dangerous goods accidents, Elaflon PTFE universal hose assembly, DDC Dry Disconnect Coupling
Ship bunkering
FHD hose assembly, flange connection
Elapharm EPH 25 OHM-G
ELAPHARM OHM G electrically conductive 'Ω / T', light grey cover. Corresponds to DIN 26055-3 / EN 16820, Type A. FDA conform. Homogeneous elastomer hose construction with smooth, black Teflon® PTFE liner.
ERV-GR 250.10 SS TA
Green Band Rubber Expansion Joint with PTFE lining
ZVA Slimline 2, filler inlet, Diesel refuelling
Composite hose assemblies with 'COPSAFE' , suitable for COP systems (cross-over prevention)
Connection road tanker to trailer: LTW hose assembly, DDC Dry Disconnect Coupling
LNG bunkering / loading of a ship
MannTek DCC Dry Cryogenic Coupling
HB hot bitumen hose - loading road tanker
MK-A 80 SS, TW female coupler with Active Safeguard Lever, VB 80 SS
Pull slider to unlock
ERV TA:
ERV with white PTFE lining. Used when the chemical resistance of the chosen ERV type is insufficient. Resistant to all commonly used liquids. Electrically isolating, therefore not suitable for flammable liquids in Ex-Zones. Admissible working temperature of expansion joint has to be observed. For maximum pressure of 6 bar – not suitable for vacuum.
ELAFLEX Hamburg
Assembling ERV large DN
Elaflex Cam and Groove Couplings ('Camlock'): AMKX 50 EASY
EASYLOC stainless steel coupler to EN 14420 - 7, with lever arrest. Picture shows the version as one-piece coupler with integrated hose tail and Spannfix stainless steel clamp
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Sand casting ZVA
LNG Refuelling
LNG Nozzle 'N-LNG' coupled to fuel, LNG 25 fill hose assembly
PHD-F aircraft refuelling hose
PHD 63 F
Polypal Plus 50 universal hose
with SFC 50 SS / SS hose flange (hose tail, swiveling flange and Spannloc clamps of stainless steel)
Chemical manifold
FEP 5O, MannTek DDC-M 5O SS
FGN 2 SS
Flange with male thread, stainless steel
DEC – Dry Evotek Couplings:
dry disconnect couplings for the chemical industry.
• Low connecting forces even against pressure
• Ergonomic handle (DN40 and bigger)
• Good transmission ratio in the cam curve
• Wide range of chemical resistance due to selection of high quality materials
• Minimized spillage during decoupling
IBC connection with reducer RS S100x3" SS
MannTek DDC-V 80, DDC-M 80, FWS 75 PP
HD 100 C, HD 10 sensing hose
Aircraft Dispenser with DN 100 hose (spiralised marking) and a sensor hose to control the hydrant system.
Flange seal FD 220-162 of ELAPAC
Slimline quality dispensing hose for the forecourt
ERV-R 80.16 ZS 2
Red Band Rubber Expansion Joint with "ZS" limiter (tie rods with outer limitation in rubber bushings)
