VB 80 Al
TW dust plug, aluminium
Camlock Cam Locking hose tails AMK-St 50 Ms and AVK-St 50 Ms (brass)
Product Badges EK 145 with design to customer specification
ZV 19.1
ZV 19 manually operated dispensing nozzle, DN 19 (3/4"), for diesel, fuel, petroleum and oils (also vegetable oils) up to 100 ltr./min.
Ship loading with chemicals
UTS 150 hose assembly, ARK-S Safety Break Coupling
SG 1" - SSB 16 Propeller
Sight Glass with SSB 16 Safety Break. Compact and lightweight combination of the functions hose swivel, Safety Break and Sight Glass (with propeller).
LNG Refuelling
LNG Safety Break for installation on LNG dispensers SB-LNG FL-J
DDC-S 2 1/2" PE
Dust plug for DDC-M 65 Dry Disconnect Coupling
ELAFLEX Hamburg
ERV pressure testing
Section view ERV-G Rubber Expansion Joint
LBS 50 foodstuff hose, RMC 50 SS foodstuff fitting with Spannloc of stainless steel
Aseptic bulk filling
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Automatic rod turning machines
Cargo loading of a tanker with petroleum based products; FHD hose assembly
Picture courtesy of Macoil International, Gibraltar
Customer protected special design ZVA Slimline 2 nozzle
Adapters / couplers for vehicles fighting dangerous goods incidents:
Adapters Foodstuff Couplings to DIN 11851 Female Rd 78 x 1/6 SS x VK 50 SS/Vi, Male Rd 78 x 1/6 SS/Vi x MK 50 SS/Vi
Helicopter refuelling winter / Canada
ZVF 50, HD 50 C NEON
RS 21/2 x3 SS
Reducer Female/Male
Rubber Expansion Joint ERV-G LT 80.16
YELLOW BAND LT expansion joints designed for low temperature applications for standard-conform petroleum based products, e.g. diesel, heating oil up to + 90° C, aviation fuels, petroleum up to + 60° C and gasoline up to + 40° C. Temperature (depending on medium) range - 40° C up to + 90° C, temporarily up to + 100° C. Electrically dissipative.
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
ZVA long term testing
Hose assembly for petroleum based products
LTW 75, VC 75-3", DDC-M 80-3"
Ship loading various media - STW 150 and UTS 150 hose assemblies
ZVF 50 JET
Manual aviation fuelling nozzle for overwing service. Flowrate up to 400 ltr. / min. (85 IGM – higher flowrates are possible). Size DN 50. Working pressure PN 10 (140 psi). Temperature range - 40° C up to + 55° C.
Unloading petroleum products at the service station (road tanker to UST)
LG 3" hose assembly for gravity discharge, LTW 50 hose assembly for vapour balance
Ship bunkering
FHD hose assemblies
LPG Autogas dispenser
ZVG 2 ACME + ZVG 2 DISH nozzle, LPG 16 hose, ARK 19 Safety Break
Safety Swivel Break
SSB 16 SS
Ship bunkering with LNG
Coupling of DCC male and female part DN 50; left hand side CBC 50 Cryogenic Breakaway Coupling
ZVF 50 helicopter refuelling with HD-C hose assembly
France
Oasis FM104 Fuel Manifold on Natural Gas powered vehicle
MK 50 SS
TW female coupler, stainless steel
