Oasis SV108_SV104 Sandwich Valves with handle, for CNG
Aircraft refuelling
Carter Underwing Nozzle, HD63C Neon, ZVF50, SC50Al, HD50C, Hose Bead BD50
GasGuard LPG nozzle GG30
LPGas nozzle with Bayonet connection according to EN 12806 - 2003 for the filling of commercial and passenger Autogas vehicles as well as mobile and small stationary storage tanks with propane and butane. New : 4-slot design to facilitate connection of the nozzle to the vehicle fill point. New nose piece design to reduce the released gas upon valve closure, incorporating improved gas release method to minimise the risk of splash back.
Petrol station in Mexico
ZVA Slimline 2 nozzle, SSB 16 Safety Break, Slimline hose assembly
ELAFLEX quality: section view of a ERV bellows
ERV VSR:
ERV with vacuum support ring. Ring of AISI 316 Ti , used when the vacuum resistance of the chosen ERV is not sufficient.
Tank storage: manifold with DDC Dry Disconnect Couplings, TW hose assemblies
Anti-Kinking Spiral 'KSS'
The main bending stress area for hose assemblies is directly behind the coupling. To reinforce this area we developed the new Anti-Kinking Spiral 'KSS': suitable for all ELAFLEX hoses, recommended for dynamically strong stressed universal hoses with thermoplastic linings
MB 80 Ms
Dust cap for VK 80, brass
L.P.Gas road tanker
Connection DDC-M 100 with HD hose assembly to tanker
Ship bunkering from the road tanker
ELAFLEX Hamburg
Coax hose assembling, colours
Oasis FV103 Fill Valve, NC 104 Nozzle Coupler, CNG bus refuelling of small truck
Universal hose UTL 50
VX 50-2" NPT SS
Male hose coupling 2" NPT of stainless steel with Spannfix clamp
Spannloc hose clamps of stainless steel for chemical hoses
Marine bunkering and cargo hoses
ship to ship cargo transfer
ZVA Slimline 2 LA nozzle with LeverAssist hold-open aid
Terminal / gantry: 'Polypal Oil' hose assemblies for bottom loading of road tankers
Lining UPE - resistant to all petrochemical media, also with high content of aromatics or other aggressive additives; cover CR - oil resistant
ELAPHARM and Tecnopal hose assemblies
VB 80 SSE
TW dust plug of stainless steel, surface in contact with the medium additionally coated with Teflon® PFA. This type is used if stainless steel does not have a sufficient chemical resistance (i.e. for hydrochloric acid and iron-III-chloride) and polypropylene is not possible because of insufficient stability. Available in all standard sizes.
Manufacturing warm forged parts
Example SC 150 Spannloc clamp
SPANNFIX pinned Sicherheits Klemmbacken aus aluminium
SX 75 Al
ELAFLEX Hamburg
Aerial view (left to right): Technical dept., small aisle stock, stock with loading ramps
Aircraft refuelling hose with reflecting stripes, Hose Beads 'BD' which notably improve the handling as they reduce friction against the tarmac, next generation overwing nozzle ZVF 50
Fuel delivery at the petrol station
LTW 75 fuel delivery hose, GPS 50 vapour balance hose
MannTek DDC-V 150 F Al, DDC-M 150-6"
TWD coupling seal
MB 50 TS SS Lockable fi ll pipe coupling
with VK 50 SS
Tecnopal chemicol hose assembly
on hose reel
