MannTek SJ swivel
ELAFLEX Hamburg
Assembling Spannloc hose clamps
Oasis FV103 with NC203 P36, Light Duty Fill Valve and Transit Nozzle for CNG
Construction site / on site refuelling:
ZVA 25 (automatic nozzle), road tanker
Terminal / gantry: 'Polypal Oil' hose assemblies for bottom loading of road tankers
Lining UPE - resistant to all petrochemical media, also with high content of aromatics or other aggressive additives; cover CR - oil resistant
Elaflex seals:
Quality is in the detail.
ZVA Slimline 2 / ZVA Slimline 2 GR
Petrol station nozzles with and without vapour recovery, hose assemblies
ELAFLEX Hamburg
Assembling Coax hoses
AMK-St 38 SSE
Camlock female coupler, hose tail for assembling with Spannfix or Spannloc. Material: stainless steel with universally resistant PFA coating (red)
V 16-1" cr
Male ferrule hose coupling EN 14424, reusable. Slimline 16 hose, blue.
Construction of ELAFLEX composite hoses type FWS
Sectioned view of a composite hose, denomination of the components – detail view
ELAFLEX Hamburg
Stock special flanges, pick by voice
Elapharm EPH 25 OHM-G with ASFB hose tail
V 19-1"
Male ferrule hose coupling EN 14424, reusable. Slimline 19 hose, black.
SPANNLOC bolted safety clamps of stainless steel
SC 75 SS
VKC 75.80 SS
TW male hose coupling, stainless steel, two part, with Spannloc clamps
ZVA Slimline 2, dispenser
Elaflon Plus FEP hose assemblies, one side open end
up to DN 50 grey cover / from DN 63 black cover
ERV-G 100 TW
ContiTech Production hose
Dispensing hose, removal of mandrel
DN 1" SS
Double nipple stainless steel
ContiTech Production hose
handling coil / logistics
ZVA Slimline 2 yellow / red / blue with SSB 16 Safety Break
AMKC 50 SS
'Camlock' stainless steel steel coupler to EN 14420 - 7 with hose tail and Spannloc clamps
LPG road tanker loading with MannTek DGC Dry Gas Couplings
ERV-BR 100.16
BR Rubber Expansion Joint, special type for abrasive media such as sludges, slurries, solid / liquid mixtures and emulsions, dustlike or powdery products. Also suitable for all kinds of water (non oil containing) as well as various chemicals. Not suitable for petroleum based products. For extreme strain (e. g. sharp and rough-edged matter) we suggest the use of ERV with inner protection sleeve type SR.
ZVA Slimline 2 GR, Bügel 1, Product Sleeve blue, Coax hose assembly with Colour Sleeve blue
ZVA Slimline 2
with Sight Glass
ZVG 2 EURO
(Push-In-Coupling) to EN 13760. One-handed operation possible.
VB 80 SSE
TW dust plug of stainless steel, surface in contact with the medium additionally coated with Teflon® PFA. This type is used if stainless steel does not have a sufficient chemical resistance (i.e. for hydrochloric acid and iron-III-chloride) and polypropylene is not possible because of insufficient stability. Available in all standard sizes.
