Fluorflex FXD universal hose assemblies

with inner corrugation for maximal flexibility. Picture 2

Rail tanker loading L.P. Gas

DGC Dry Gas Couplings, SBC Safety Breakaway Couplings

VKC 75 SS

TW male hose coupling, stainless steel, one part, with Spannfix clamps, with protecting "K"-Ring

ElaSil® Silicone hose assemblies

Connecting Triclamp

Hose Reel with hydraulic rewind system blue, TW 100, DDC-M 100

Anti-Kinking Spiral 'KSS'

The main bending stress area for hose assemblies is directly behind the coupling. To reinforce this area we developed the new Anti-Kinking Spiral 'KSS': suitable for all ELAFLEX hoses, recommended for dynamically strong stressed universal hoses with thermoplastic linings

IBC unloading

Female hose coupling MC 38-S60 SS (with Spannfix clamps) and LMS solvent hose. Direct connection of a hose assembly to the IBC.

Yellow Band hoses from Elaflex

Setting the standard for refuelling hoses

Underwing refuelling, HD-C

Aircraft dispenser, pit

HD 10 C sensing hose

Use as sensing hose for aircraft dispensers (hydrant dispensers)

Marine bunkering and cargo hoses

ship to shore bunkering

Urea solution filling, truck: ZVA HV for AdBlue® nozzle

Hose assemblies for petroleum based products

Yellow Band quality with nozzle, TW coupling, flange connection

SBS 250 - marine cargo hoses with built-in nipples

heavy standard bunkering hose to EN 1765, category S 15

Boat refuelling, ZVA 25

Yellow band aircraft refuelling hose, hose coupling with male thread, Spannloc aus Aluminium

HD 50 C, VC 50 SS, SC 50 Al

ELAPHARM Type EPH-OHM G

electrically conductive 'OHM/T', with light grey cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, black PTFE liner.

Elaflon PTFE 50

Universal hose with electrically conductive, seamless lining of PTFE (Polytetrafluorethylene). Suitable for all commonly used chemicals. Suitable for both suction and delivery (Type PTFE D = delivery). Working pressure up to 16 bar, burst pressure > 64 bar. Temperature range from - 30° up to + 150° Celsius (depending on medium). Steaming out for cleaning and sterilisation permissible up to 150° C, max. 30 min. Meets EN 12115. FDA und USP Class VI conform according EC regulations 1935/2004 and 10/2011.

ZVA Slimline 2 GR, black, guard 3 - bottom view

Slimline quality dispensing hose for the forecourt

Swivel EA 075 A f. ZVA HV for AdBlue®

new design

Lube oil filling, ZV 19 manual nozzle

IBC Hose Coupling MC 38-S 60 SS, MX 38-S 60 SS

direct connection to the standard outlet S 60 of IBC

DEC – Dry Evotek Couplings:

dry disconnect couplings for the chemical industry.
• Low connecting forces even against pressure
• Ergonomic handle (DN40 and bigger)
• Good transmission ratio in the cam curve
• Wide range of chemical resistance due to selection of high quality materials
• Minimized spillage during decoupling

Slimline 16 green

Quality dispensing hose for the forecourt

Loading Brine (salt solutíon for winter service): CHS hose asssembly, DDC Dry Disconnect Coupling

Fluorflex FXD universal hose assembly

extremely flexible PTFE hose with maximum bending radius

NB-ZVF 50 SR, ER 583 PTL, HD-C 38

Nozzle boot f. ZVF 50 with additional spout retainer

ZVF 25 with EKG and GKG

Manual nozzle DN 25 for aircraft overwing refuelling, with ground cable assembly, dust cap assembly and AVGAS sticker (decal)

NR ferrule hose fittings, non reattacheable
