MB 80 Ms
Dust cap for VK 80, brass
Unloading chemical road tanker
Elaflon PTFE hose assembly, TW couplings
Universal hose assembly UTD 19 with MC 19 SS
L.P. Gas rail tanker
loading and unloading with DGC Dry Gas Couplings, LPG hose assemblies. Vehicle side: DGC-V male couplings with flange
PHD-F aircraft refuelling hose
PHD 63 F
ZVA Slimline 2 TMV nozzle for Diesel with DRIP STOP spout
Elaflon PTFE
Universal hose with electrically conductive, seamless lining of PTFE (Polytetrafluorethylene). Suitable for all commonly used chemicals. Suitable for both suction and delivery (Type PTFE D = delivery). Working pressure up to 16 bar, burst pressure > 64 bar. Temperature range from - 30° up to + 150° Celsius (depending on medium). Steaming out for cleaning and sterilisation permissible up to 150° C, max. 30 min. Meets EN 12115. FDA und USP Class VI conform according EC regulations 1935/2004 and 10/2011.
Construction of ELAFLEX composite hoses type FWS
Sectioned view of a composite hose, denomination of the components – detail view
Oasis DMI Dispenser Manifold for CNG
ERV-R 1000.10
"Red Band" Rubber Expansion Joints DN 1000; wastewater pump
Lightweight Gravity Discharge Road Tanker Hose LG 3"
with VX 75-3" Al LG
ZVF 50 UL for aircraft refuelling with ER 494
EA 909 green, EK 946 green
Ship bunkering
'Yellow Band' collapsible high
Fluorline EFL 21
Universal pump hose DN 21 for chemicals, petroleum based products, for propane, butane and other L.P. gases, as well as solvents. Ideal for highly sensitive media such as AdBlue® urea solution. Temperature range - 40° to + 100° C. Burst pressure > 64 bar.
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Plettenberg factory 2
Filling of chemicals with nozzles
UTS hose assemblies, ZVA TD nozzles special type for chemicals
MK-A 80 SS, TW female coupler with Active Safeguard Lever, VB 80 SS
Solvent filling with integrated vapour recovery in the nozzle
ZVA 25 GR, UTS hose assemblies
Road tanker reel with HD 50 hose assembly, ZV 500 nozzle
Filling of Heating Oil Tanks: Adapter KR 50-21/2"
for difficult to reach filler inlets
Bellows ERV-GR (Green Band) without flanges, with VSD vakuum support spiral
VSD: to increase vacuum resistance of a chosen ERV type. Open ring of stainless steel 1.4571
Hose Reels group picture
Movable, pneumatic rewind system, active Vapour Recovery (VR) for gasoline fuels
Manufacturing of turned parts
V 16-3/4"
Male ferrule hose coupling EN 14424, reusable. Slimline 16 hose, yellow.
Connection road tanker to trailer: LTW hose assembly, DDC Dry Disconnect Coupling
ELAFLEX Hamburg
Assembling ERV small DN
Construction site / on site refuelling:
ZVA 500 manual bulk nozzle (shut off by limit switch), HD hose assembly, road tanker
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Sand casting
AMKI 25 SS, AVKI 25 SS
'Camlock' stainless steel female and male coupling to EN 14420 - 7
FWS composite hoses / hose assemblies
Type FWS PP with female threaded fitting, Type FWS PTFE with stainless steel flange
