Safety Swivel Break
SSB 16 SS
Elaflon Plus FEP 50
Camlock cam locking couplings
top left – ELAFLEX standard version; bottom right – ELAFLEX EASYLOC version
Hose assembly for petroleum based products
LTW 75, VC 75-3", DDC-M 80-3"
VX 50-2" SS
Male hose coupling 2" BSP of stainless steel with Spannfix clamp
Rail tanker unloading of petroleum based products
with FWS 80 PP St/St composite hoses and MannTek Dry Disconnect Couplings
SFC 38 SSE
Swiveling flange hose coupling with Spannfix clamps. Material: stainless steel with universally resistant PFA coating (red)
Ship bunkering
HD hose assembly on dispenser vehicle
ELAFLEX Hamburg
Assembling dispensing hose
HD-C LT, Low Temperature
Antarctica: Low Temperature aircraft refuelling hoses in action; fuel transfer from drums via mobile pump
Elapharm EPH-OHM with welding end
MK 80-3" AG Ms
TW coupler of brass, to EN 144260-6. Special type with 3" male BSP connection
"Yellow Band" Rubber Expansion Joints, aircraft dispenser
ERV-G 200, ERV-G 150
Rubber Expansion Joint ERV-G LT 80.16
YELLOW BAND LT expansion joints designed for low temperature applications for standard-conform petroleum based products, e.g. diesel, heating oil up to + 90° C, aviation fuels, petroleum up to + 60° C and gasoline up to + 40° C. Temperature (depending on medium) range - 40° C up to + 90° C, temporarily up to + 100° C. Electrically dissipative.
ELAFLEX refuelling equipment for LPG (Autogas, L.P.Gas)
IBC Adapter RS S60x2 SS
MannTek Safety Breakaway Coupling SBC 80 SS F
with flange connection
SG 1" 1x0 Al Propeller
Sight Glass with propelller, to EN 13617-1, DN 25, for installation between petrol station nozzle and hose assembly, or mounting on the dispenser. For the visual control of bubble-free dispensing and fuel colour (e. g. for premium fuels). Suitable for all standardised gasoline and diesel fuels according EN 589 + EN 590, including ethanol or biodiesel content, also Avgas and Jet-A1.
Locomotive refuelling
Dispenser, ZV 32 DB nozzles with Renk coupling
L.P.Gas petrolstation, GG20, Slimline, ZVG 2 EURO UL
oasis TH Tank Head Valves, CNG trailer
Filling plant for special gasoline types
ZVA 25 solvent type with special seals, Slimline hose assemblies
ZVA Slimline 2 with Splashguard, Slimline hose assembly blue
Malaysia
Rail tanker unloading of petroleum based products
LTW hose assemblies, TW couplings
Hose Reel with hydraulic rewind system orange, LPG 32, DGC-M 50
ELAPHARM Type EPH 25
electrically isolating 'I', with blue cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, white PTFE liner. Clamp fittings, lining flared (free of dead spaces).
Construction of ELAFLEX composite hoses type FWS
Sectioned view of a composite hose, denomination of the components (English)
MannTek DGC DryGasCouplings for L.P. Gas
DGC-M 80-3", DGC-V 80-3" with DDC-K dust cap
DDC-V 50 F Aseptic
MannTek Dry Disconnect Coupling, DN 50, stainless steel, with Aseptic flange
ERV-CR ... ZS
"CR" Rubber Expansion Joints; water purification plant
