V 16-3/4"
Male ferrule hose coupling EN 14424, reusable. Slimline 16 hose, yellow.
ERV-G 150 TW, ERV-G 100 TW, ERV-G 80 TW
LPG road tanker loading with MannTek DGC Dry Gas Couplings
Dispenser at the airport
ZVA 25 Avgas for overwing refuelling
Ship bunkering with LNG
DCC Dry Cryogenic Coupling with cap; CBC Cryogenic Breakaway Coupling
L.P. Gas rail tanker
loading and unloading with DGC Dry Gas Couplings, LPG hose assemblies. Vehicle side: DGC-V male couplings with flange
ERV with FSH:
Flame protection cover (closed)
ZVA Slimline 2 LA nozzle with LeverAssist hold-open aid
Elapharm EPH 25 with DIN 11858 fitting, free of dead spaces
MK 80-90 SS; MK coupling stainless steel with bent lever 90°
TW coupling with bent lever: For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.
NB-ZVF 50 SR, ER 583 PTL, Aljac Closed Circuit Sampler (CCS)
Nozzle boot f. ZVF 50 with additional spout retainer
Unloading petroleum products at the service station (road tanker to UST)
LG hose assembly for gravity discharge
MKC 75 SS
TW female one-part coupler, stainless steel
V 63 2½" SS
Hose coupling with male thread
UTL 50 universal chemical hose assembly and TW female coupler MKC 50 SS
Elaflon Plus FEP
hose assemblies, lacquer filling
ELAFLEX Hamburg
Construction
LPG Autogas Adapter (filler inlet) BAYO
Bayonet connection
Sand casted products to your design
In our modern foundry we can produce complex sand casted aluminium, bronze and gunmetal products to your requirements.
Unloading petroleum products at the service station (road tanker to UST)
LG 3" hose assembly for gravity discharge, LTW 50 hose assembly for vapour balance
ELAFLEX Hamburg
Hose assemblies pressure testing (hydrostatic test)
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Sample inspection
Unloading petroleum products at the service station (road tanker to UST)
LTW hose assembly, MK 80-32° Ms couplers with bent lever. The lever shall always be fully closed for safety reasons. For applications with limited room.
Rubber Expansion Joint ERV-GS HNBR 80.16
YELLOW STEEL HNBR expansion joints for petroleum based products, DIN EN fuels up to 50 % aromatic content, cooling water with oily anticorrosion additives, lubrication and hydraulic oil, seawater. Very good aging, weathering and ozone resistance. Temperature range (depending on medium) - 35° C up to + 100° C, temporarily up to + 120° C. Fire resistant to ISO 15540 up 30 min. at + 800° C. Electrically dissipative.
Oasis FV103 180° Fill Valve for CNG
MK 80 Ms
TW coupler of brass, to EN 144260-6 with 3" female BSP connection
Oasis Engineering Ltd, New Zealand (CNG refuelling products)
Production Picture 22
Cargo loading of a tanker with petroleum based products; FHD hose assembly with new longitudinal stripe to avoid torsion
Picture courtesy of Macoil International, Gibraltar
Rail tanker unloading of petroleum based products
Plant side: FWS PP St/St composite hoses, SG 3" Sight Glasses
Oil production Kuwait
TW and STW hose assemblies with SFC hose flanges
