Elaflex refuelling equipment:
Quality is in the detail.
Hose assembly TW 63 with VX 63-11/2" and DDC-M 65 Al
TW hose with Dry Disconnect Coupling
ZVA Slimline 2
Automatic nozzle DN 19, for flowrate max. 80 l / min. Product Sleeve EK 043 blue, Slimline dispensing hose assembly
Camlock cam locking couplings:
Attachment AVB dust plug with chain to Spannloc clamps (service free of charge)
ELAFLEX refuelling equipment:
Quality is in the detail.
L.P. Gas rail tanker
loading and unloading with DGC Dry Gas Couplings, LPG hose assemblies. Vehicle side: DGC-V male couplings with flange
ZVF 50 JET for aircraft refuelling
Bellows ERV-GR (Green Band) without flanges, with VSD vakuum support spiral
VSD: to increase vacuum resistance of a chosen ERV type. Open ring of stainless steel 1.4571
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Plettenberg factory 2
Functioning principle of MannTek DDC Dry Disconnect Couplings
closed - open
VB 50 SSE
TW dust plug of stainless steel, surface in contact with the medium additionally coated with Teflon® PFA. This type is used if stainless steel does not have a sufficient chemical resistance (i.e. for hydrochloric acid and iron-III-chloride) and polypropylene is not possible because of insufficient stability. Available in all standard sizes.
ELAFLEX Hamburg
Ship bunkering
HD hose assembly on dispenser vehicle
SSB 32, SSB 25, SSB16
Safety Swivel Breaks (SSB)
Refuelling equipment for petroleum based products:
Elaflex "Yellow Band" Hose assemblies, ERV Rubber Expansion Joints
Sample Collection Unit
DDC-M 25 Dry Disconnect Couplings and HD hose assembly for sample collection of aircraft fuel
ELAFLEX Hamburg
ERV flange assembly medium sizes
ZVA Slimline 2 and ZVA Slimline 2 GR
Dispenser, Czech Republic
LNG Refuelling
LNG Nozzle 'N-LNG'
Hot stamping process, production TW coupling parts
BK 3 SS
Cap with 3" female BSP thread, stainless steel
Oasis FV103 Fill Valve, CNG service station
Adapters / couplers for vehicles fighting dangerous goods incidents:
Adapters Flange FGN 2" SS x VK 50 SS/Vi, FGN 3" SS x VK 50 SS/Vi, FGN 4" SS x VK 50 SS/Vi
HD 38 C, VX 38 - 11/2 Sn
Hose assembly for aircraft refuelling, fitting in contact with medium tin plated
M 21-1" NR cr
Female ferrule hose coupling EN 14424, factory assembled, non-reattacheable. Slimline 21 hose, blue.
Section view of a DS 2 swivel
Manufacturing warm forged parts
Example SC 150 Spannloc clamp
ERV-OR
"Orange Band" Rubber Expansion Joints for L.P. Gas, depot
ERV-G 100.16 SS TA
Yellow Band Rubber Expansion Joint PTFE lining
Petrol station in Singapore
ZVA Slimline 2 nozzle with Splashguard, SSB 16 Safety Break, Slimline hose assemblies
