Media Library / Images

ZVA 25 for aircraft refuelling

red plastic cover (scuffguard), decal (sticker) AVGAS, dust cap and ground cable assembly

DDC-M 65-2 1/2" Al

MannTek Dry Disconnect Coupling, aluminium

DAC-V 65, DAC-M 65

Coupling test facility

Rail tanker unloading of petroleum based products

LTW hose assemblies; Poland

DDC-M 100, HD-C, airport depot

Dry Disconnect Coupling, Yellow Band hose, at airport depot

ERV-CR 100 (4")

'CR' Rubber Expansion Joint for cold and warm water / ship engine room

DAC-V 65, DAC-M 65

Aircraft refueller , Dry Aircraft Coupling to ISO 45 for bottom loading - in action

FWS composite hoses / hose assemblies

Type FWS PP with female threaded fitting, Type FWS PTFE with stainless steel flange

Sideway storage of hose assemblies, tank truck for petrol station delivery

LG 3" hose assembly for gravity discharge, LG 2" hose assembly for vapour balance

Hose assembly TW 63 with SFX 63

TW hose with helix, 'TW' flange with hose tail and Spannfix clamps of aluminium

ZVF 50 PTL (Push-Twist-Lock), strainer inspection

ERV-G AF

Suitable for piping systems of aviation refuelling or dispensing vehicles in accordance to EN ISO 1825/EI 1529. Suitable for all aviation fuels.

SG 1" 1x0 Al Propeller

Sight Glass with propelller, to EN 13617-1, DN 25, for installation between petrol station nozzle and hose assembly, or mounting on the dispenser. For the visual control of bubble-free dispensing and fuel colour (e. g. for premium fuels). Suitable for all standardised gasoline and diesel fuels according EN 589 + EN 590, including ethanol or biodiesel content, also Avgas and Jet-A1.

ELAFLEX Hamburg

Delivery trucks, loading ramps

LPG ship-to-ship cargo transfer

Danchem PASS composite hose

LNG Refuelling

N-LNG Nozzle, pull back handles to uncouple

ZVA 25 with Z-Swivel

Boat Refuelling, Hose Reel

Slimline 21 blue

Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360 and EN 13483.

Cargo loading of a tanker with petroleum based products; FHD hose assembly

Picture courtesy of Macoil International, Gibraltar

DN 1" SS

Double nipple stainless steel

Ship bunkering loading and unloading, Hose Reels, HD hose, ZV 500

Bunkerboat

ERV-R 200x175.16 ZS 4

Red Band Rubber Expansion Joint, special length 175 mm, with "ZS" limiter (tie rods with outer limitation in rubber bushings)

SPANNLOC bolted safety clamps of aluminium

SC 75 Al

Adapters / couplers for vehicles fighting dangerous goods incidents:

Dry Disconnect Stanag 3756 DDC- M 50 / 65 / 80 SS NOT x VK 50 SS/Vi Hose sided MK coupling can be coupled without tools

LNG Refuelling

N-LNG Nozzle, push handles to couple

Terminal, TW hose assemblies and DDC Dry Disconnect Couplings

ELAFLEX Hamburg

ERV inner protection sleeve/tube "SR"

ERV-G 100.16

YELLOW BAND Rubber Expansion Joint suitable for petroleum based products with aromatic content up to 50%, fuels (ethanol content up to 85 %), aviation fuels, town gas and natural gas except liquefied petroleum gas. Temperature range (depending on medium) - 20° C up to + 90° C, temporarily up to + 100° C. Electrically dissipative.

SG 1 1x0 SS for Nozzles for AdBlue®

Attach on dispenser side of swivel

RMC 25 SS

Hose coupling with female foodstuff thread and Spannloc clamps
