ERV-CR 100 (4")
'CR' Rubber Expansion Joint for cold and warm water / ship engine room
Ship sided connectors for bunkeringof fuel, lube oils, fresh water; unloading of sewage
DDC Dry Disconnect Couplings with caps
TSVC 100 hose connectors
Fittings to conect two hose assemblies - available in many sizes, with Spannloc or Spannfix clamps
Oasis FV103 Fill Valve with extension, CNG dispenser
Polypal Plus 50 universal hose
with SFC 50 SS / SS hose flange (hose tail, swiveling flange and Spannloc clamps of stainless steel)
ZVG 2 ACME nozzle for L.P. Gas / Autogas
visible: Magnet within the guard for the dispenser Reed Switch
L.P. Gas rail tanker
loading and unloading with DGC Dry Gas Couplings, LPG hose assemblies. Vehicle side: DGC-V male couplings with flange
Hose assemblies
for dangerous goods: ELAFLEX quality
MC 38-11/2" Ms
Female hose coupling for hoses, brass, with Spannloc clamps
Hose Connection with TW coupling, TSG 3" Sight Glass
MK 80-32° coupling with bent lever. For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.
Bunker boat: HD hose assembly on reel, ZV 500 nozzle
Elaflon Plus FEP 75, MK-A 80 SS
Loading and unloading of chemicals. TW coupling with active safeguard lever
H2 Hydrogen group picture
ERV-H2+, H2 hydrogen hose assembly, Oasis Ball Valves, Check Valves
Oasis NC 103-200 Bus & Truck Nozzle
Elaflon Plus FEP hose assemblies:
Bulk filling of powders
Bunkering ship: FHD hose assemblies
Hose assembly for petrol stations
Standard hose SL 16
MK 80 Ms
TW coupler of brass, to EN 144260-6 with 3" female BSP connection
HD-C aircraft refuelling hose
HD 50 C F
DDC-M 80 SS; SG 3", VC 75-3, Elaflon FEP 75, DDC-K 3" SS ADR
Epoxy resin loading with Dry Disconnect Coupling, sight glass and FEP universal hose. DDC cap with pressure relief at container tank outlet.
ERV-R 100.16
RED BAND Rubber Expansion Joint for water, drinking water (DVGW W 270 as well as ACS, conform to FDA), cold and warm waste water, seawater, cooling water, also with chemical additives for water treatment, low concentrated acids and alkalis, salt solutions, technical alcohols, esters and ketones. Can be used in oily athmospheric environments, e.g. engine rooms. Temperature range - 40° C up to + 100° C, temporarily up to + 120° C. Electrically dissipative.
MK 80 SS, TW couplers stainless steel
Spannfix safety clamps SX 75 SS of stainless steel
DDC-M 50 F Aseptic
MannTek Dry Disconnect Coupling with Aseptic flange
ZVA 32 for aircraft refuelling
black plastic cover (scuffguard), Sight Glass, dust cap and ground cable assembly
AMKX 50 Ms
'Camlock' brass steel coupler to EN 14420 - 7 with hose tail and Spannfix clamps
HB hot bitumen hose - loading plant
Elaflex hose assemblies, nozzles and Rubber Expansion Joints for the chemical industry
ELAFLEX Hamburg
Construction
DG 50 Al - new Aluminium swivel for ZVF 50
Section view
