Oasis FV103 Fill Valve, CNG refuelling

Oasis FV103 Fill Valve, CNG refuelling

Vehicle refuelling with LPG (L.P. Gas, Autogas)

Vehicle refuelling with LPG (L.P. Gas, Autogas)

ZVG 2 ACME nozzle, LPG 16 hose

Marking of High Temperature Types ZVA Slimline 2 / ZVA Slimline 2 GR

Marking of High Temperature Types ZVA Slimline 2 / ZVA Slimline 2 GR

For regions with exceptionally hot summer conditions which may lead to particularly high fuel temperatures we offer High Temperature (HT) nozzle types, available for ZVA Slimline 2 and ZVA Slimline 2 GR.

ZVA Slimline 2 nozzle with hose assembly

ZVA Slimline 2 nozzle with hose assembly

ELAPHARM and SD Pyropal steam hose

ELAPHARM and SD Pyropal steam hose

Pharmaceutical production

Rubber Expansion Joint ERV-GS HNBR 80.16

Rubber Expansion Joint ERV-GS HNBR 80.16

YELLOW STEEL HNBR expansion joints for petroleum based products, DIN EN fuels up to 50 % aromatic content, cooling water with oily anticorrosion additives, lubrication and hydraulic oil, seawater. Very good aging, weathering and ozone resistance. Temperature range (depending on medium) - 35° C up to + 100° C, temporarily up to + 120° C. Fire resistant to ISO 15540 up 30 min. at + 800° C. Electrically dissipative.

Elaflex hose assemblies and Rubber Expansion Joints for petroleum based products

Elaflex hose assemblies and Rubber Expansion Joints for petroleum based products

ZV 19.1 TD

ZV 19.1 TD

ZV 19 manually operated dispensing nozzle, DN 19 (3/4"), up to 100 ltr./min. Special version for chemicals/solvents with PTFE seals.

ZVA 32 for aircraft refuelling

ZVA 32 for aircraft refuelling

black plastic cover (scuffguard), Sight Glass, dust cap and ground cable assembly

CNG Safety Break (Hose Break)

CNG Safety Break (Hose Break)

connected

Lube oil plant: manifold with DDC-V Dry Disconnect Couplings

Lube oil plant: manifold with DDC-V Dry Disconnect Couplings

ERV-G Yellow Band rubber expansion joint, exhausty sytem of a yacht

ERV-G Yellow Band rubber expansion joint, exhausty sytem of a yacht

Bonding reel grey, high visibility bonding cable with clamp

Bonding reel grey, high visibility bonding cable with clamp

KWZ x VK 80

KWZ x VK 80

Rail car adapter with TW male coupling

Hose Reel with HD 38, ZVA 25, Bonding Reel red

Hose Reel with HD 38, ZVA 25, Bonding Reel red

Mobile Cabinet, airfield refuelling

BD 63, Hose Beads at airport depot

BD 63, Hose Beads at airport depot

ELAFLEX Hamburg

ELAFLEX Hamburg

Visual quality checks

Storz coupling; water connector ship

Storz coupling; water connector ship

ELAFLEX Hamburg

ELAFLEX Hamburg

Coax hose assembling, colours

Hot stamping process, production TW coupling parts

Hot stamping process, production TW coupling parts

Example of a marking of test data (hydrostatic test) of a hose assembly

Example of a marking of test data (hydrostatic test) of a hose assembly

Check Valve 350 bar

Check Valve 350 bar

for Hydrogen

Hose assembly with MKX 75 SS and VB 80 SS

Hose assembly with MKX 75 SS and VB 80 SS

TW female coupler with Spannfix clamp, plug

HD-C NEON hose with new, REFLECTING marking

HD-C NEON hose with new, REFLECTING marking

ELAFLEX Hamburg

ELAFLEX Hamburg

Hose assemblies, marking after testing

ZVG 2 K (Korea)

ZVG 2 K (Korea)

uncoupling from J 15 filler connection

ZVF 50 JET

ZVF 50 JET

Manual aviation fuelling nozzle for overwing service. Flowrate up to 400 ltr. / min. (85 IGM – higher flowrates are possible). Size DN 50. Working pressure PN 10 (140 psi). Temperature range - 40° C up to + 55° C.

Hose assemblies for petroleum based products

Hose assemblies for petroleum based products

Yellow Band quality with nozzle, TW coupling, flange connection

VB 80 SSE

VB 80 SSE

TW dust plug of stainless steel, surface in contact with the medium additionally coated with Teflon® PFA. This type is used if stainless steel does not have a sufficient chemical resistance (i.e. for hydrochloric acid and iron-III-chloride) and polypropylene is not possible because of insufficient stability. Available in all standard sizes.

Rubber Expansion Joint ERV-R 80.16

Rubber Expansion Joint ERV-R 80.16

RED BAND expansion joints for water, drinking water (approvalDVGW W 270 as well as ACS, conform to FDA), cold and warm waste water, seawater, cooling water, also with chemical additives for water treatment, low concentrated acids and alkalis, salt solutions, technical alcohols, esters and ketones. Can be used in oily athmospheric environments, e.g. engine rooms. Temperature (depending on medium) - 40° C up to + 100° C, temporarily up to + 120° C. Electrically dissipative.
