Aircraft refuelling

Carter Underwing Nozzle, HD 63 C Neon, ZVF 50 AVGAS, SC 50 Al, HD 50 C, Hose Bead BD 50

ZVA Slimline 2 LA nozzle with LeverAssist hold-open aid

and Slimline dispensing hose, yellow

ERV-W 80.16

WHITE BAND Rubber Expansion Joint for foodstuffs, also containing oil and fat. Liner corresponds to Recommendation XXI of BfR and FDA-21CFR 177.2600. Not approved for drinking water. Temperature range (depending on medium) - 20° C up to + 90° C, temporarily up to 100° C. Electrically non-conductive.

Cargo loading of a tanker with petroleum based products; FHD hose assembly

Picture courtesy of Macoil International, Gibraltar

Oasis DMI Dispenser Manifold for CNG

ZVA Slimline 2, guard no. 8D, black scuffguard, red product sleeve, SL 16 hose assembly with red colour sleeve

Oasis SV 108 Sandwich Valves 1" on CNG trailer

Dispenser picture to distinguish the three different kinds of Safety Breaks

Hose Break, Pump Break, Nozzle Break

LeverAssist hold-open aid for ZVA Slimline 2 nozzles

Detail

MK 80-90 SS; MK coupling stainless steel with bent lever 90°

TW coupling with bent lever: For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.

Alternative fuels: DME Dimethyl Ester

DGC Dry Gas Coupling, EFL 16 Fluorline hose assembly

LPG Autogas Adapter (filler inlet) EURO

Push-In-Coupling EN 13670

KW bronze corrugated pipe with cathodic protection

Cathodic protection flexible pipe connector (bronze corrugated pipe) for electrically insulating, cathodically protected installations. Installed in manhole of a petrol station underground storage tank (UST). Suction pipes towards the dispenser pumps - and directly underneath the dispensers

Production MannTek, Sweden

Elaflon PTFE 50

Universal hose with electrically conductive, seamless lining of PTFE (Polytetrafluorethylene). Suitable for all commonly used chemicals. Suitable for both suction and delivery (Type PTFE D = delivery). Working pressure up to 16 bar, burst pressure > 64 bar. Temperature range from - 30° up to + 150° Celsius (depending on medium). Steaming out for cleaning and sterilisation permissible up to 150° C, max. 30 min. Meets EN 12115. FDA und USP Class VI conform according EC regulations 1935/2004 and 10/2011.

VK 80 - 2" IG Ms

TW male coupling brass, with reduced female BSP connection, one piece adapter (special type)

Hose Reel Spring Rewind

HD 25 C, ZVA 25 AF red, GKG 25, EKG 1200

Overwing refuelling ZVA 25

HD-C hose assembly

ZVA Slimline 2, Splashguard, Slimline 16 hose assembly

Solvent filling with integrated vapour recovery in the nozzle

ZVA 25 GR, UTS hose assemblies

Adapters / couplers for vehicles fighting dangerous goods incidents:

Adapter Rail Tanker Dischharge Coupling KWK SS/Vi x VK 50 SS/Vi

Ship sided connectors for bunkeringof fuel, lube oils, fresh water; unloading of sewage

DDC Dry Disconnect Couplings with caps

IBC

with CHS chemical hose assembly

ZVA Slimline 2 DSA, Prepay Dispenser

DSA: Pressure Controlled Safety Shut-Off

Marine bunkering and cargo hoses

ship to shore bunkering

MK-A 80 SS

MK 80 SS with active safeguard lever

GasGuard LPG nozzle GG30:

with Splashguard

KWZ x MK 80-32°

Rail car adapter with TW coupler, bent lever

Group picture

TW 100, DDC-M100 4", Hose Reel VR Spring Rewind System, ZVA Slimline 2 GR, ERV-G 1000, ERV-BR 300

ERV ZSS:

Tied Flanges – Tie rods with inner and outer limitation
