ERV-R Red Band rubber expansion joint, ship engine room
Sample Collection Unit
DDC-M 25 Dry Disconnect Couplings and HD hose assembly for sample collection of aircraft fuel
MK 80-2" IG
TW female coupler, brass, with reduced female thread (special type)
Ship bunkering with LNG
DCC Dry Cryogenic Coupling with cap; CBC Cryogenic Breakaway Coupling
LTW 75 hose assembly
with MKX 75.80 Ms
Polypal Clean hose assembly
Pharmaceutical production
Manifold, Ultra Fast Fill Quick Coupler 350 bar
for Hydrogen
Rail tanker toploading, TW 100 hose assemblies
TGN 4" Al tank truck flange with threaded nipple, VK 100 Ms male TW coupler, MB 100 Al dust cap, chain
Composite hose Danoil 7GG, DDC-M Dry Disconnect Coupling, airport depot
ERV-G
Pump station for fuels
ELAFLEX hose quality: braided reinforcements
serve for flexibility, low weight and increased lifetime
Storz coupling; water connector ship
Filling of chemicals with nozzles
UTS hose assemblies, ZVA TD nozzles special type for chemicals
Yellow band aircraft refuelling hose, hose coupling with male thread, Spannloc aus Aluminium
HD 50 C, VC 50 SS, SC 50 Al
Vehicle refuelling with LPG (L.P. Gas, Autogas)
GasGuard GG30 BAYO nozzle with Bayonet connector and optional splashguard
ELAFLEX Hamburg
CAD construction
LNG Refuelling
LNG truck refuelling with 'N-LNG' Nozzle coupled to fuel, LNG 25 fill hose assembly with cover, bonding cable
Vehicle refuelling with LPG (L.P. Gas, Autogas)
ZVG 2 DISH nozzle, LPG 16 hose assembly, ARK 19 Safety Break
Construction of ELAFLEX composite hoses type FWS
Sectioned view of a composite hose, denomination of the components (German)
SBS 250 - marine cargo hoses with built-in nipples
heavy standard bunkering hose to EN 1765, category S 15
RS 3/4 x 1 SS
Reducer Female/Male
Elaflon PTFE 50
Universal hose with electrically conductive, seamless lining of PTFE (Polytetrafluorethylene). Suitable for all commonly used chemicals. Suitable for both suction and delivery (Type PTFE D = delivery). Working pressure up to 16 bar, burst pressure > 64 bar. Temperature range from - 30° up to + 150° Celsius (depending on medium). Steaming out for cleaning and sterilisation permissible up to 150° C, max. 30 min. Meets EN 12115. FDA und USP Class VI conform according EC regulations 1935/2004 and 10/2011.
ZVA Slimline 2 LT & ZVA Slimline 2 GR LT nozzles
Use of special seals for cold regions
Elaflex hoses
FEP, UTS, PCS, HD, LPG, PTFE, CHS
LPG 16 orange
Hose assembly for L.P. Gas, with anti-kinking sleeve and Colour Sleeve
VKC 75 SS
TW male hose coupling, stainless steel, one part, with Spannfix clamps, with protecting "K"-Ring
Slimline 21 hose assembly with non reattacheable female coupling M 21-1" NR
Railtanker
MannTek DDC-V 80 F Dry Disconnect Couplings (tank unit with flange), Pressure Caps PN 25 with pressure relief
ERV-G AF
Suitable for piping systems of aviation refuelling or dispensing vehicles in accordance to EN ISO 1825/EI 1529. Suitable for all aviation fuels.
