1720 images found




Hose assemblies for the chemical industry

Hose assemblies for the chemical industry

ERV-GR TA, UTL with DDC, FXD with male thread, Elaflon Plus FEP with foodstuff fitting, Elaflon PTFE with female thrad

Road tanker hose assembly

Road tanker hose assembly

with VKC 75 SS (TW male coupling stainless steel, one part, with Spannloc clamps, K-Ring), dust cap VB 80 SS & chain

Camlock cam locking couplings:

Camlock cam locking couplings:

Attachment AMB dust cap with chain to Spannfix clamps (service free of charge)

ZVA Slimline 2 GR nozzles

ZVA Slimline 2 GR nozzles

Fuel grade identification for ZVA to standard

Fuel grade identification for ZVA to standard

Attach with EK 145 Product Badge

Adapters / couplers for vehicles fighting dangerous goods incidents:

Adapters / couplers for vehicles fighting dangerous goods incidents:

Adapter Sight Glass SG 2" SS/Vi with MK 50 SS/Vi and VK 50 SS/Vi

Filling of Heating Oil Tanks: Adapter KR 50-2 3/4" (Switzerland)

Filling of Heating Oil Tanks: Adapter KR 50-2 3/4" (Switzerland)

for difficult to reach filler inlets

ELAFLEX Hamburg

ELAFLEX Hamburg

Stock special flanges, pick by voice, scanning

ZVA Slimline 2 with SG 1" Al Sight Glass

ZVA Slimline 2 with SG 1" Al Sight Glass

PAL hoses for the chemical industry

PAL hoses for the chemical industry

Tecnopal 38

Tecnopal 38

Chemical hose to EN 12115 for alkalis, acids, solutions, alcohols, polar solvents, acetates, aldehydes, esters, ketones, hot water, hot air (not oily).

ELAFLEX Hamburg

ELAFLEX Hamburg

Hose stock

FFC 50.16 SS

FFC 50.16 SS

Fixed flange hose fitting of stainless steel, with Spannloc clamps

oasis TH104 Tank Head Valves, CNG trailer

oasis TH104 Tank Head Valves, CNG trailer

Elaflex product configurators

Elaflex product configurators

for quick and easy product choice / RFQ

UTL 50 universal chemical hose assembly and TW female coupler MKC 50 SS

UTL 50 universal chemical hose assembly and TW female coupler MKC 50 SS

M 21-1" cr

M 21-1" cr

Female ferrule hose coupling EN 14424, reuasable. Slimline 21 hose, yellow.

DN 2" Ms

DN 2" Ms

Double nipple brass

Stainless steel hose tails - new shape

Stainless steel hose tails - new shape

Stainless steel hose tails - optimized shape for enhanced operational safety, suitable for temperatures up to 150° C. Details see Information 5.15.

LNG ship bunkering

LNG ship bunkering

DCC 100 Dry Cryogenic Coupling, CBC 100 PERC Cryogenic Breakaway Coupling

Anti-Kinking Spirals 'KSS' and 'KSS-SD'

Anti-Kinking Spirals 'KSS' and 'KSS-SD'

The main bending stress area for hose assemblies is directly behind the coupling. To reinforce this area we developed the Anti-Kinking Spiral 'KSS': suitable for all ELAFLEX hoses, recommended for dynamically strong stressed universal hoses with thermoplastic linings

PAL hoses for the chemical industry

PAL hoses for the chemical industry

ELAPHARM Type EPH 25

ELAPHARM Type EPH 25

electrically isolating 'I', with blue cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, white PTFE liner. Clamp fittings, lining flared (free of dead spaces).

Road tanker for heating oil delivery, HD hose assembly, ZV 500 nozzle, MK 80 Ms coupler with VB 80 P dust plug

Road tanker for heating oil delivery, HD hose assembly, ZV 500 nozzle, MK 80 Ms coupler with VB 80 P dust plug

GasGuard GG11R

GasGuard GG11R

The GasGuard GG11 Back-Check Valve (GG11R: with additional release screw) should be standard equipment for any LPGas road tanker operator. It is used in conjunction with LPGas bulk refueling nozzles to contain leaks at storage tank fill points. If the fill point proves to be leaking when removing the nozzle it can be left on the tank until corrective action is taken. The driver can move to the next fill point without delay.

Adapter / Safety Breakaway Coupling for rail tanker loading / unloading

Adapter / Safety Breakaway Coupling for rail tanker loading / unloading

SBC 100 Safety Breakaway Coupling with RV-KW 51/2", RV-VK 80

Aircraft refuelling hose with reflecting stripes, Hose Beads 'BD' which notably improve the handling as they reduce friction against the tarmac, next generation overwing nozzle ZVF 50

Aircraft refuelling hose with reflecting stripes, Hose Beads 'BD' which notably improve the handling as they reduce friction against the tarmac, next generation overwing nozzle ZVF 50

DDC-M 100, TW hose assembly

DDC-M 100, TW hose assembly

Rail tanker bottom loading with Dry Disconnect Coupling

ELAFLEX Hamburg, large new narrow aisle stock 2018 for hoses

ELAFLEX Hamburg, large new narrow aisle stock 2018 for hoses

ZV 19.1 TD

ZV 19.1 TD

ZV 19 manually operated dispensing nozzle, DN 19 (3/4"), up to 100 ltr./min. Special version for chemicals/solvents with PTFE seals.
