EA 866 scuffguard: fuel grade identification 'LPG' to standard
The scuffguard for LPG / Autogas nozzles shows the LPG fuel grade marking required by standard, and offers a large advertising space
L.P. Gas rail tanker
loading and unloading with DGC Dry Gas Couplings, LPG hose assemblies. Vehicle side: DGC-V male couplings with flange
ELAFLEX Hamburg
CAD construction
SPANNLOC bolted safety clamps of aus stainless steel
SC 75 SS
Safety Crimping Ferrule of stainless steel
SH 50 SS
HD 100 C NEON, HD 10 C sensing hose
Type HD-C, aviation hose
Elaflex AB, Sweden
ZVA 25 spout with stainless steel tip
MK-A 80 SS, TW female coupler with Active Safeguard Lever
connected: hose assembly with VKX 75.80 SS
ARK 19 Safety Break (Hose Break) at LPG Autogas dispenser
Reassembly on site without tools
Rail tanker loading and unloading of petroleum based products
LPG Autogas Adapter (filler inlet) BAYO
Bayonet connection
LPG road tanker loading with MannTek SBC Safety Breakaway Couplings
MK 80 Ms
TW coupler of brass, to EN 144260-6 with 3" female BSP connection
Rail car adapter type KWZ, one end with rail car thread 5½, other end 3" male BSP
ELAFLEX quality: section view of a ERV bellows
ERV-OR "Orange Band"
Hose assemblies
Universal hose UTS 50 with DDC-M 50-2"; Tanker hose for petroleum based products LTW 75 with DDC-M 80-3"
Assembling Spannloc hose fittings
ELAFLEX refuelling equipment:
Quality is in the detail.
SBS 250 - marine cargo hoses with built-in nipples
EN 1765, category S 15
DDC-M 80-3" SS
MannTek Dry Disconnect Coupling, DN 80, stainless steel
ELAFLEX Hamburg
Nozzle stock, ZVA Slimline 2 GR
ELAFLEX Tanktechnik, Production Plettenberg / Germany
Assembling ZVA
Oasis Engineering Ltd, New Zealand (CNG refuelling products)
Development
Ship bunkering
HD hose assembly on dispenser vehicle
Adapter: MK 50-45° SS x VK 50 SS
The lever is bent to enable lever arrest (safe position when coupled)
Hose assemblies for the chemical industry
ERV-GR TA, UTL with DDC, FXD with male thread, Elaflon Plus FEP with foodstuff fitting, Elaflon PTFE with female thrad
GasGuard GG11R
The GasGuard GG11 Back-Check Valve (GG11R: with additional release screw) should be standard equipment for any LPGas road tanker operator. It is used in conjunction with LPGas bulk refueling nozzles to contain leaks at storage tank fill points. If the fill point proves to be leaking when removing the nozzle it can be left on the tank until corrective action is taken. The driver can move to the next fill point without delay.
Filling of Heating Oil Tanks: Adapter KR 50-21/2"
for difficult to reach filler inlets
HD-C, airport depot
Underwing couplings with HD-C hoses for bottom loading of aircraft refuellers at airport depot
