Dust cap for VK 80, aluminium

ERV-G AF

Suitable for piping systems of aviation refuelling or dispensing vehicles in accordance to EN ISO 1825/EI 1529. Suitable for all aviation fuels.

L.P.Gas road tanker

ZVA Slimline 2 nozzles with splashguard, Slimline hose assemblies

Refuelling at a petrol station in the United Arab Emirates

BD 63 Hose Beads

to EI 1522 standard - notably improve handling as they reduce friction against the tarmac. They additionally protect against hose abrasion. 'BD' Hose Beads are highly break resistant, contain no bolts or nuts, can be easily assembled or disassembled and are suitable for reeling.

GasGuard LPG nozzle GG30:

with Splashguard

FFVF Full Flow Ball Valve, ERV-G ... TW

Aircraft refueller

Saturated steam hose fitting SMS 19-3/4" SS/SS

completely of stainless steel, with self-securing bolts and nuts; possibility to attach stainless steel anti-kinking spirals KSS-SD

Bunker boat: HD hose assembly on reel, ZV 500 nozzle

RS 1 x 11/4 SS

Reducer Female/Male

Elaflex hoses

SD, PTFE, LPG, TW, FEP, SL

ZV 500 nozzle for heating oil, hose assembly

ELAPHARM and SD Pyropal steam hose

Pharmaceutical production

Hose Assemblies with Flange - Elapac seals

Flange seal: Elapac.

DCC Dry Cryogenic Coupling for LNG

with cap

ZVA 32 for aircraft refuelling

black plastic cover (scuffguard), Sight Glass, dust cap and ground cable assembly

ZAF Coax adapter (splitter valve) at petrol station dispenser

ELAFLEX Hamburg

Aerial view (left to right): Technical dept., small aisle stock, stock with loading ramps

ELAFLEX Hamburg

Assembling Spannloc hose clamps

Rubber Expansion Joint ERV-G LT 80.16

YELLOW BAND LT expansion joints designed for low temperature applications for standard-conform petroleum based products, e.g. diesel, heating oil up to + 90° C, aviation fuels, petroleum up to + 60° C and gasoline up to + 40° C. Temperature (depending on medium) range - 40° C up to + 90° C, temporarily up to + 100° C. Electrically dissipative.

IBC loading and unloading

MannTek DDC-M 50, FWS 50 PTFE

ELAPHARM Type EPH 25

electrically isolating 'I', with blue cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, white PTFE liner. Clamp fittings, lining flared (free of dead spaces).

Overview "From terminal to nozzle"

Fuel delivery at the petrol station

LTW 75 fuel delivery hose

Anti-Kinking Spirals 'KSS' and 'KSS-SD'

The main bending stress area for hose assemblies is directly behind the coupling. To reinforce this area we developed the Anti-Kinking Spiral 'KSS': suitable for all ELAFLEX hoses, recommended for dynamically strong stressed universal hoses with thermoplastic linings

SFC 38 SSE

Swiveling flange hose coupling with Spannfix clamps. Material: stainless steel with universally resistant PFA coating (red)

SD 38 Pyropal

Steam hose with steel braids for wet saturated steam up to 18 bar (210° C) and hot water up to 120° C. For cold water up to 25 bar. Minimum burst pressure 180 bar (1 : 10 safety factor

ERV TA:

ERV with white PTFE lining. Used when the chemical resistance of the chosen ERV type is insufficient. Resistant to all commonly used liquids. Electrically isolating, therefore not suitable for flammable liquids in Ex-Zones. Admissible working temperature of expansion joint has to be observed. For maximum pressure of 6 bar – not suitable for vacuum.

HD 100 C, HD 10 sensing hose

Aircraft Dispenser with DN 100 hose (spiralised marking) and a sensor hose to control the hydrant system.

VK 80-2" AG Ms

TW male coupling brass, with reduced male BSP connection (special type)
