BD 63, HD 63 C
Aircraft refuelling hoses with ELAFLEX Hose Beads 'BD'. Details see Information 7.17
HD-C, airport depot
Underwing couplings with HD-C hoses for bottom loading of aircraft refuellers at airport depot
ZVG 2 Swivel
Easy rotating swivel EA 820
ZVA Slimline 2 GR, hand
scuffguard and product sleeve green, Slimline hose assembly with Colour Sleeve green
Premium refuelling equipment from ELAFLEX
DDC-M 100, TW hose assembly
Rail tanker bottom loading with Dry Disconnect Coupling
ZVF 50 JET
Manual aviation fuelling nozzle for overwing service. Flowrate up to 400 ltr. / min. (85 IGM – higher flowrates are possible). Size DN 50. Working pressure 10 bar (140 psi). Temperature range -40° C up to +55° C
Group picture
TW 100, DDC-M100 4", Hose Reel VR Spring Rewind System, ZVA Slimline 2 GR, ERV-G 1000, ERV-BR 300
ZVF 50 UL 91 / green
Manual aviation fuelling nozzle for overwing service. Flowrate up to 400 ltr. / min. (85 IGM – higher flowrates are possible). Size DN 50. Working pressure PN 10 (140 psi). Temperature range - 40° C up to + 55° C.
Ship bunkering with LNG
CBC Cryogenic Breakaway Coupling from MannTek and hose assembly for cryogenic media
VC 65-21/2" SS / SS
Spannloc threaded hose coupling with BSP male thread / Spannloc of stainless steel
Oasis CV Heavy Duty Check Valves for CNG
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Assembling hall, meterial logistics
ELAFLEX Hamburg
Nozzle stock, ZVG 2 DISH
VB 80 Al
TW dust plug, aluminium
DAC-V 65, DAC-M 65
Aircraft refueller , Dry Aircraft Coupling to ISO 45 for bottom loading - with and without sight glass
Rubber Expansion Joint ERP 80.16
RED SPOT expansion joints for sanitary installations, highly flexible, for cold and warm water, pool water, sea water, drinking water. Temperature range (depending on medium) - 40° C up to + 90° C, temporarily up to + 120° C. Electrically dissipative.
Safety Swivel Break
SSB 25
Lube oil plant: manifold with DDC-V Dry Disconnect Couplings
SBS 250 - marine cargo hoses with built-in nipples
EN 1765, category S 15
MC 38-11/2" SS
Female hose coupling for hoses, stainless steel, with Spannloc clamps
MK 80 Ms
TW coupler of brass, to EN 144260-6 with 3" female BSP connection
ELAFIX 40
Magnet adapter for installation in filler necks from DN 40. This adapter allows the refilling of urea solution with ZVA HV for AdBlue®, without the risk of misfillings. Meets ISO 22241-4.
Customer protected special design ZVA Slimline 2 & ZVA Slimline 2 GR nozzles
Vehicle refuelling with LPG (L.P. Gas, Autogas)
ZVG 2 ACME nozzle, LPG 16 hose
DDC-M 25-1" SS
MannTek Dry Disconnect Coupling, DN 25, stainless steel
ERV-GR 250.10 SS TA
Green Band Rubber Expansion Joint with PTFE lining
DCC Dry Cryogenic Coupling for LNG
Coupling process
Connection aircraft refueller to flanged hose assembly
ERV-G 100 TW, HD 100 C, TW-flange
